Description
Mobile rack for 1x HDD/SSD for 1x 5.25" bay with lock
The fact that the HDD does not need to be screwed to a tray makes the HDD installation much faster. A 5.25" bay is needed on the PC. SATA HDDs are supported SATA I/II/III.
No fan = whisper silent
This mobile rack is made almost completely from aluminium, only the front and back panels are made of hard plastic. Aluminium is very stable, very light and on top of everything else, it dissipate heat perfectly. That is why no fan is needed in order to protect the HDDs. In case still wished, a 12V fan can be installed (not delivered in the package).
No worries = locked
In order that the HDD will stay protected at all times, a lock was added. In this way, no unauthorized person will be able to reach your data. An LED indicator provides information regarding HDD access and activity.
Key Features
- Mobile Rack with HDD Carrier
- Supports all 3.5"/2.5" SATA/SAS 1.5/3.0/6.0 Gbit/s HDDs (1" high) in a 5.25" bay
- Fits in a standard 5.25" bay
- Special aluminium case for better heat evacuation
- Supports Hot Swap
- Key lock to prevent improper operation
- Fanless design, no noise
- 12V power connector for addional fan by need
Description
No tray = double the speedThe fact that the HDD does not need to be screwed to a tray makes the HDD installation much faster. A 5.25" bay is needed on the PC. SATA HDDs are supported SATA I/II/III.
No fan = whisper silent
This mobile rack is made almost completely from aluminium, only the front and back panels are made of hard plastic. Aluminium is very stable, very light and on top of everything else, it dissipate heat perfectly. That is why no fan is needed in order to protect the HDDs. In case still wished, a 12V fan can be installed (not delivered in the package).
No worries = locked
In order that the HDD will stay protected at all times, a lock was added. In this way, no unauthorized person will be able to reach your data. An LED indicator provides information regarding HDD access and activity.
Specifications
| Features | |
|---|---|
| Country of origin | China |
| HDD size | 2.5/3.5" |
| Hot-swap | Yes |
| Key lock | Yes |
| Supported storage drive heights | 25.4 mm |
| Type | Bezel panel |
| Size (imperial) | 13.3 cm (5.25") |
| Number of HDDs supported | 1 |
| Number of fans | 0 fan(s) |
| HDD interface | SATA, SATA II, SATA III, Serial Attached SCSI (SAS) |
| Data transfer rate | 6 Gbit/s |
| Product colour | Black |
| Material | Aluminium |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Country of origin | China |
| HDD size | 2.5/3.5" |
| Hot-swap | Yes |
| Key lock | Yes |
| Supported storage drive heights | 25.4 mm |
| Type | Bezel panel |
| Size (imperial) | 13.3 cm (5.25") |
| Number of HDDs supported | 1 |
| Number of fans | 0 fan(s) |
| HDD interface | SATA, SATA II, SATA III, Serial Attached SCSI (SAS) |
| Data transfer rate | 6 Gbit/s |
| Product colour | Black |
| Material | Aluminium |
| Products per master (outer) case | 20 pc(s) |
| Master (outer) case width | 420 mm |
| Master (outer) case gross weight | 11.3 kg |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 262 mm |
| Package width | 154 mm |
| Package height | 46 mm |
| Package depth | 197 mm |
| Harmonized System (HS) code | 84733080 |
| Ports & interfaces | |
| Card reader integrated | No |
| External SATA ports quantity | 2 |
| Storage | |
| Card reader integrated | No |
| Weight & dimensions | |
| Width | 146 mm |
| Weight | 422 g |
| Height | 41 mm |
| Depth | 186 mm |
| Packaging data | |
| Package weight | 563 g |
| Package width | 154 mm |
| Package height | 46 mm |
| Package depth | 197 mm |
| Packaging content | |
| Number of lock keys included | 2 pc(s) |
| Number of screws | 8 |
| Quantity per pack | 1 pc(s) |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Logistics data | |
| Country of origin | China |
| Products per master (outer) case | 20 pc(s) |
| Master (outer) case width | 420 mm |
| Master (outer) case gross weight | 11.3 kg |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 262 mm |
| Harmonized System (HS) code | 84733080 |
