Description
Mid Tower Case 460 x 240 x 460mm
Mid Tower Case
Flow Luxury
F-LUX Platform, abbreviation of Flow Luxury, features ultra case structure design for excellent airflow and 5 fans included, delivering enhanced GPU cooling performance.
Flux Airflow
Multi-directional vent design, featuring extensive air intakes at the bottom, power supply chamber and lower sides, along with top vents and large-area mesh at the front, creating a dedicated Antec Flux airflow channel.
Description
FLUX REARMid Tower Case
Flow Luxury
F-LUX Platform, abbreviation of Flow Luxury, features ultra case structure design for excellent airflow and 5 fans included, delivering enhanced GPU cooling performance.
Flux Airflow
Multi-directional vent design, featuring extensive air intakes at the bottom, power supply chamber and lower sides, along with top vents and large-area mesh at the front, creating a dedicated Antec Flux airflow channel.
Specifications
| Technical details | |
|---|---|
| Number of 5.25" bays | 0 |
| Number of 3.5" bays | 1 |
| Number of 2.5" bays | 2 |
| Supported motherboard form factors | ATX, ITX, micro ATX |
| Supported HDD sizes | 2.5,3.5" |
| Product colour | Black |
| Number of expansion slots | 7 |
| Maximum CPU cooler height | 18 cm |
| Maximum graphics card length | 40 cm |
| Maximum PSU length | 17 cm |
| Type | PC |
| Form factor | Midi Tower |
| Material | |
| Material | Steel, Plastic, Wood |
| Indication | |
| Illumination location | Case fans |
| Illumination colour | Multi |
| Illumination | Yes |
| Ergonomics | |
| Cable management | Yes |
| On/off button | Yes |
| Design | |
| Anti-dust filter | Yes |
| Material | Steel, Plastic, Wood |
| Number of 5.25" bays | 0 |
| Number of 3.5" bays | 1 |
| Number of 2.5" bays | 2 |
| Supported motherboard form factors | ATX, ITX, micro ATX |
| Illumination location | Case fans |
| Illumination colour | Multi |
| Illumination | Yes |
| Cable management | Yes |
| Product colour | Black |
| Number of expansion slots | 7 |
| Maximum CPU cooler height | 18 cm |
| Maximum graphics card length | 40 cm |
| Maximum PSU length | 17 cm |
| Type | PC |
| Form factor | Midi Tower |
| On/off button | Yes |
| Tempered glass panel(s) | Yes |
| RGB control button | Yes |
| Power supply | |
| Power supply included | No |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Combo headphone/mic port | Yes |
| Cooling | |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,140,240,280,360 mm |
| Front fans installed | 2x 140 mm |
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 140 mm |
| Rear fans installed | 1x 140 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 120,140 mm |
| Bottom fans installed | 2x 120 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
| Liquid cooling capability | Yes |
| Pulse-width modulation (PWM) support | Yes |
| Storage | |
| Supported HDD sizes | 2.5,3.5" |
| Weight & dimensions | |
| Width | 240 mm |
| Depth | 460 mm |
| Height | 460 mm |
| Weight | 8.18 kg |
| Packaging data | |
| Package weight | 9.72 kg |
