Description
4000 ANSI Lumens 1080p Laser Business/Education Projector
Bright, Compact, Durable
The LSD400HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.
Bright Images for Large Venues
Delivering 4,000 ANSI Lumens, the LSD400HD provides vibrant and sharp projection in 1080p FHD for meeting rooms, classrooms and golf simulation setups.
Unmatched Contrasts, Enhanced Visibility
Experience enhanced visuals with the LSD400HD, boasting high contrast thanks to DLP technology and an advanced 0.65" DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience.
Ultra-Large Screen with Lower Cost-per-Inch
This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.
Save on Costs and Energy
With its advanced lamp-free light source, the LSD400HD offers a highly energy-efficient and cost-saving display solution by consuming up to 59% less power than competing projectors.
Reliable Long-Term Performance with DLP Projection Technology
With DLP technology, the LSD400HD maintains consistent color performance over time, free from any yellowing issues. Featuring a sealed engine design (IP6X), it is filter-free, preventing dust from affecting internal components and ensuring minimal maintenance. Moreover, it offers crisp and seamless image quality, displaying remarkable contrast and eliminating the noticeable screen-door effect.
Enhanced Installation Flexibility
Equipped with a 1.1x optical zoom, the projector allows users to choose the most ideal set-up location within a range, getting the desired image size without needing to change the existing interior design. .
Get Perfectly-Shaped Images Effortlessly
Horizontal and vertical keystone correction, along with 4-corner adjustment features, eliminate crooked or distorted images for a perfectly proportioned picture every time.
Versatile Creative Applications
The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
Brilliant Colors for an Authentic Golf Experience
Powered by ViewSonic’s advanced color-tuning technology, the projector features a dedicated Golf Mode that enhances colors, especially greens and blues, more vivid and brings fairways and putting surfaces to life with striking realism, creating a golf experience that feels as close to reality as possible
HDR / HLG / 4K UHD supported by HDMI 2.0b
The LSD400HD is equipped with HDMI 2.0b and HDCP 2.2 ports, delivering full 4K resolution with HDR10 and HLG support at a smooth 60Hz frame rate. Whether streaming via a Roku stick or playing from a 4K Blu-ray player, enjoy brilliant whites, rich blacks, and enhanced detail for a truly cinematic visual experience.
Upgrade Your Projector with Wireless Content Casting
Enhance your projector with the ViewShare Wireless Screen Casting Kit for seamless wireless content sharing. The projector‘s built-in 5V/1.5A USB-A output powers the dongle, enabling simultaneous multimedia streaming and power charging without adapters.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily via USB cable connection with your laptop. This efficient solution, developed exclusively by ViewSonic, ensures optimal performance without the hassle.
Key Features
- 3rd generation laser phosphor technology with a lifespan up to 30,000 hours
- 4,000 ANSI Lumens and 1080p resolution for clear images in any environment
- High native contrast ratio powered by a 0.65” DMD chip DLP technology
- Up to a 300" ultra-large screen with a lower cost-per-inch
- Up to 59% less power consumption than competing lamp projectors
- Installation flexibility: H/V keystone, 4 corner adjustment, and 360° projection
Description
The LSD400HD is part of ViewSonic’s Luminous Superior Series, a lamp-free projector lineup designed for commercial and educational environments. Powered by 3rd-generation laser phosphor technology, it provides 4,000 ANSI Lumens brightness and an impressive lifespan of up to 30,000 hours. Its lamp-free design ensures eco-friendliness and cost-efficiency by reducing up to 59% power consumption than competing lamp projectors. Delivering ultra-large projections up to 300” in 1080p resolution, this projector leverages high native contrast from a 0.65” DMD chip with DLP technology. Equipped with a 1.1x optical zoom, H/V keystone & 4 corner correction, and 360° projection, the LSD400HD supports flexible installation options, making it an excellent choice for meeting rooms, classrooms, and golf simulation setups.Bright, Compact, Durable
The LSD400HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.
Bright Images for Large Venues
Delivering 4,000 ANSI Lumens, the LSD400HD provides vibrant and sharp projection in 1080p FHD for meeting rooms, classrooms and golf simulation setups.
Unmatched Contrasts, Enhanced Visibility
Experience enhanced visuals with the LSD400HD, boasting high contrast thanks to DLP technology and an advanced 0.65" DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience.
Ultra-Large Screen with Lower Cost-per-Inch
This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.
Save on Costs and Energy
With its advanced lamp-free light source, the LSD400HD offers a highly energy-efficient and cost-saving display solution by consuming up to 59% less power than competing projectors.
Reliable Long-Term Performance with DLP Projection Technology
With DLP technology, the LSD400HD maintains consistent color performance over time, free from any yellowing issues. Featuring a sealed engine design (IP6X), it is filter-free, preventing dust from affecting internal components and ensuring minimal maintenance. Moreover, it offers crisp and seamless image quality, displaying remarkable contrast and eliminating the noticeable screen-door effect.
Enhanced Installation Flexibility
Equipped with a 1.1x optical zoom, the projector allows users to choose the most ideal set-up location within a range, getting the desired image size without needing to change the existing interior design. .
Get Perfectly-Shaped Images Effortlessly
Horizontal and vertical keystone correction, along with 4-corner adjustment features, eliminate crooked or distorted images for a perfectly proportioned picture every time.
Versatile Creative Applications
The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
Brilliant Colors for an Authentic Golf Experience
Powered by ViewSonic’s advanced color-tuning technology, the projector features a dedicated Golf Mode that enhances colors, especially greens and blues, more vivid and brings fairways and putting surfaces to life with striking realism, creating a golf experience that feels as close to reality as possible
HDR / HLG / 4K UHD supported by HDMI 2.0b
The LSD400HD is equipped with HDMI 2.0b and HDCP 2.2 ports, delivering full 4K resolution with HDR10 and HLG support at a smooth 60Hz frame rate. Whether streaming via a Roku stick or playing from a 4K Blu-ray player, enjoy brilliant whites, rich blacks, and enhanced detail for a truly cinematic visual experience.
Upgrade Your Projector with Wireless Content Casting
Enhance your projector with the ViewShare Wireless Screen Casting Kit for seamless wireless content sharing. The projector‘s built-in 5V/1.5A USB-A output powers the dongle, enabling simultaneous multimedia streaming and power charging without adapters.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily via USB cable connection with your laptop. This efficient solution, developed exclusively by ViewSonic, ensures optimal performance without the hassle.
Specifications
| Projector | |
|---|---|
| Number of colours | 1.07 billion colours |
| Projector native resolution | 1080p (1920x1080) |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 0.98 - 10.76 m |
| Contrast ratio (typical) | 3000000:1 |
| Zoom capability | Yes |
| Vertical synchronization (min) | 0.024 kHz |
| Vertical synchronization (max) | 0.12 kHz |
| Matrix type | DMD |
| Matrix size | 1.65 cm (0.65") |
| Keystone correction, vertical | +-30° |
| Keystone correction, horizontal | +-30° |
| Horizontal synchronization (min) | 15 kHz |
| Horizontal synchronization (max) | 135 kHz |
| Projection technology | DLP |
| Projector brightness | 4000 ANSI lumens |
| Smart projector | No |
| Screen size (max) | 7.62 m (300") |
| Lamps | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source brightness | 4400 lm |
| Lens system | |
| Zoom capability | Yes |
| Focus | Manual |
| Focal length range | 21.86 - 24 mm |
| Aperture range (F-F) | 2.5 - 2.67 |
| Vertical lens shift range | 0 - 60% |
| Throw ratio | 1.48 - 1.62 |
| Optical zoom | 1.1x |
| Offset | 132% |
| Digital zoom | 2x |
| Video | |
| Full HD | Yes |
| 3D | No |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Supported graphics resolutions | 640 x 480 (VGA), 3840 x 2160 |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 15 W |
| Ports & interfaces | |
| HDMI connector type | Full-size |
| HDMI version | 2.0 |
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Composite video in | 0 |
| Audio (L/R) in | 0 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| DVI port | No |
| Component video (YPbPr/YCbCr) in | 0 |
| USB 2.0 Type-A ports quantity | 1 |
| Network | |
| Smart TV | No |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Storage | |
| Card reader integrated | No |
| Sound emission | |
| Noise level | 32 dB |
| Noise level (economic mode) | 27 dB |
| Technical details | |
| Product colour | White |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| Quantity per pack | 1 pc(s) |
| Image lag time | 16.7 ms |
| Performance | |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| Noise level | 32 dB |
| Noise level (economic mode) | 27 dB |
| Features | |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| Noise level | 32 dB |
| Noise level (economic mode) | 27 dB |
| HDCP version | 2.2 |
| Multimedia | |
| Built-in speaker(s) | Yes |
| RMS rated power | 15 W |
| Design | |
| Product type | Standard throw projector |
| Product colour | White |
| Cable lock slot | Yes |
| Display | |
| Built-in display | No |
| Power | |
| AC adapter output voltage | 19.5 V |
| AC input voltage | 100 - 240 V |
| Power source | AC |
| Power consumption (typical) | 143 W |
| Power consumption (standby) | 0.5 W |
| Packaging data | |
| Package width | 400 mm |
| Package depth | 280 mm |
| Package height | 155 mm |
| Package weight | 4.5 kg |
| Security | |
| Cable lock slot | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Package width | 400 mm |
| Package depth | 280 mm |
| Package height | 155 mm |
| Weight | 3 kg |
| Width | 286 mm |
| Depth | 216 mm |
| Height | 129 mm |
| Package weight | 4.5 kg |
| Packaging content | |
| Remote control included | Yes |
| Warranty card | Yes |
| Cables included | AC |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
