Description
5-Pack, SC/APC, ITU-G.984 GPON WAN, 1/2.5 GbE RJ45, 1.2 Gbps uplink / 2.5 Gbps downlink, up to 20 km, PoE, 5W, 76.5 x 76.5 x 26.4 mm
Description
A GPON optical network unit with a 2.5 GbE port that delivers 1.2 Gbps uplink / 2.5 Gbps downlink speeds at distances up to 20 km.Specifications
| Network | |
|---|---|
| VLAN support | Yes |
| Ethernet LAN data rates | 1000,2500 Mbit/s |
| Maximum data transfer rate | 2488 Mbit/s |
| Fiber optic connector | SC/APC |
| Performance | |
| Wavelength | 1490 nm |
| Maximum transfer distance | 20000 m |
| Tx power (min) | 1.5 dBmW |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -8 dBmW |
| Rx power (max) | -28 dBmW |
| Features | |
| Reset button | Yes |
| Housing material | Polycarbonate (PC) |
| LED indicators | LAN, Power, Status |
| Product colour | Black, White |
| Internal | No |
| Ports & interfaces | |
| Power over Ethernet (PoE) ports quantity | 1 |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC/APC |
| Power | |
| Power consumption (max) | 5 W |
| Power over Ethernet (PoE) | Yes |
| Input voltage | 24 V |
| Weight & dimensions | |
| Width | 76.5 mm |
| Depth | 76.5 mm |
| Weight | 78 g |
| Height | 26.4 mm |
| Operational conditions | |
| Operating temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Housing material | Polycarbonate (PC) |
| Wavelength | 1490 nm |
| Maximum transfer distance | 20000 m |
| Tx power (min) | 1.5 dBmW |
| Tx power (max) | 5 dBmW |
| Rx power (min) | -8 dBmW |
| Rx power (max) | -28 dBmW |
| Internal | No |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication | |
| LED indicators | LAN, Power, Status |
| Design | |
| Housing material | Polycarbonate (PC) |
| LED indicators | LAN, Power, Status |
| Product colour | Black, White |
| Internal | No |
| Management features | |
| Reset button | Yes |
| Colour | |
| Product colour | Black, White |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Logistics data | |
| Quantity per pack | 5 pc(s) |
