Description
1/2.8" CMOS, 2 MP, 1080p, 3.9-46.8mm, USB, RJ-45, PoE+, 158.8x200x162.2 mm
When distance learning and hybrid classrooms are the new normal, the AVer DL30 is a must-have solution for online education. With the DL30 connected to a laptop, you can present freely onstage while livestreaming so students can learn no matter where they are. Teachers don’t need to be camera shy anymore—they can just be themselves and teach how they want thanks to the DL30 tracking camera!
Key Features
- Distance Learning
- Hybrid Classroom
- Full HD 1080p Resolution
- 12X Optical Zoom
- Human Detection
- Presenter Mode
- Zone Mode
- IP / USB Outputs
Description
Distance Learning Tracking CameraWhen distance learning and hybrid classrooms are the new normal, the AVer DL30 is a must-have solution for online education. With the DL30 connected to a laptop, you can present freely onstage while livestreaming so students can learn no matter where they are. Teachers don’t need to be camera shy anymore—they can just be themselves and teach how they want thanks to the DL30 tracking camera!
Specifications
| Video | |
|---|---|
| Video formats supported | H.264, M-JPEG, YUY2 |
| Supported video modes | 1080p |
| Maximum frame rate | 60 fps |
| Maximum video resolution | 1920 x 1080 pixels |
| Megapixel (approx.) | 2 MP |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system | |
| Optical zoom | 12x |
| Digital zoom | 2x |
| Focal length range | 3.9-46.8 mm |
| Minimum illumination | 0.5 lx |
| Camera | |
| Diagonal field of view | 84.1° |
| Interface | USB |
| Built-in flash | No |
| Camera shutter speed | 1/4 - 1/10000; 1/3 - 1/10000 s |
| Viewing angle, horizontal | 76.5° |
| Viewing angle, vertical | 47.3° |
| Zoom capability | Yes |
| White balance | Auto, Manual |
| Product colour | Black |
| Power | |
| Power consumption (typical) | 12 W |
| Operating voltage | 12 V |
| Performance | |
| Camera HD type | Full HD |
| PTZ control | Yes |
| Diagonal field of view | 84.1° |
| Optical zoom | 12x |
| Digital zoom | 2x |
| Focal length range | 3.9-46.8 mm |
| Camera shutter speed | 1/4 - 1/10000; 1/3 - 1/10000 s |
| Viewing angle, horizontal | 76.5° |
| Viewing angle, vertical | 47.3° |
| Zoom capability | Yes |
| White balance | Auto, Manual |
| Video formats supported | H.264, M-JPEG, YUY2 |
| Supported video modes | 1080p |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Power consumption (typical) | 12 W |
| Operating voltage | 12 V |
| Noise reduction | Yes |
| Minimum illumination | 0.5 lx |
| Maximum frame rate | 60 fps |
| Maximum video resolution | 1920 x 1080 pixels |
| Megapixel (approx.) | 2 MP |
| Privacy camera | Yes |
| Operating current | 2 A |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Design | |
| Sensor type | CMOS |
| Interface | USB |
| Built-in flash | No |
| Tilt speed | 45 °/sec |
| Tilt angle range | -90 - 90° |
| Pan speed | 90 °/sec |
| Pan range | -170 - 170° |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| LED indicators | Yes |
| Product colour | Black |
| Country of origin | Taiwan |
| Software | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Weight & dimensions | |
| Width | 232 mm |
| Depth | 228 mm |
| Height | 346 mm |
| Weight | 1.62 kg |
| Packaging data | |
| Quantity | 1 |
| Package width | 260 mm |
| Package height | 387 mm |
| Package depth | 486 mm |
| Package weight | 7.12 kg |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Remote control included | Yes |
| Box contents | Camera, Remote Control, Power Adapter, Power Cord, USB Cable, Cable Ties (x4), Cable Fixing Plate (x1), M2 x 4mm Screws (x2), 1/4'-20L 7.5mm Screw (x1), Quick Start Guide |
| Technical details | |
| Quantity | 1 |
| Tilt speed | 45 °/sec |
| Tilt angle range | -90 - 90° |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Pan speed | 90 °/sec |
| Pan range | -170 - 170° |
| Noise reduction | Yes |
| LED indicators | Yes |
| Harmonized System (HS) code | 8517691000 |
| Network | |
| Supported network protocols | IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP |
| Logistics data | |
| Products per pallet | 60 pc(s) |
| Products per master (outer) case | 2 pc(s) |
| Country of origin | Taiwan |
| Harmonized System (HS) code | 8517691000 |
| Other features | |
| Country of origin | Taiwan |
| Supported network protocols | IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP |
