Description
21.5" 1920x1080 FHD 250 nit 250nit Panel, HDMI Audio In RS232C IN RJ45(LAN) USB IR IN, Wi-Fi, webOS, 8GB
22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.
High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.
A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.
USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.
Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.
Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.
Key Features
- Brightness(Typ.) : 250 cd/m²
- Bezel : 16.3mm
- Depth : 53.8mm
- Interface : HDMI(2) / USB 2.0 / RS232C / RJ45 / IR / Audio
- USB Plug & Play, Built-in Wi-Fi
Description
22" Signage with More Utility for Commercial Space22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.
High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.
A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.
USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.
Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.
Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.
Specifications
| Display | |
|---|---|
| Panel type | IPS |
| Display number of colours | 16.78 million colours |
| LED backlighting type | Edge-LED |
| Touchscreen | No |
| Display diagonal | 54.6 cm (21.5") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 250 cd/m² |
| HD type | UHD+ |
| Response time | 14 ms |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 400000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| Ports & interfaces | |
| Remote (IR) input | 1 |
| USB port | Yes |
| HDMI version | 2.2 |
| RS-232C | Yes |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 2 |
| Audio (L/R) in | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0 |
| USB ports quantity | 1 |
| OPS module slot | No |
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 2 W |
| Built-in speaker(s) | Yes |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Bezel width (top) | 1.63 cm |
| Bezel width (side) | 1.63 cm |
| Bezel width (bottom) | 1.63 cm |
| Product colour | Black |
| Panel mounting interface | 100 x 100 mm |
| Certification | CB / NRTL FCC Class "A" / CE |
| VESA mounting | Yes |
| Performance | |
| Purpose | Universal |
| Operating hours (hours/days) | 16/7 |
| Wi-Fi | Yes |
| Power | |
| Power consumption (typical) | 30 W |
| Power consumption (standby) | 15 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | |
| Internal memory | 8 GB |
| Weight & dimensions | |
| Width | 510.3 mm |
| Depth | 53.8 mm |
| Height | 302.1 mm |
| Weight | 3.34 kg |
| Display width | 510.3 mm |
| Display depth | 53.8 mm |
| Display height | 302.1 mm |
| Display weight | 3.34 kg |
| Packaging data | |
| Package width | 565 mm |
| Package depth | 103 mm |
| Package height | 357 mm |
| Package weight | 4.74 kg |
| Remote control included | Yes |
| Cables included | AC, HDMI |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC, HDMI |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Certificates | |
| Certification | CB / NRTL FCC Class "A" / CE |
| Technical details | |
| VESA mounting | Yes |
| Panel type | IPS |
| LED backlighting type | Edge-LED |
| Sustainability certificates | ErP |
| Thin Client | |
| Internal memory | 8 GB |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Features | |
| Harmonized System (HS) code | 85285210 |
| Other features | |
| Panel type | IPS |
| Wi-Fi | Yes |
| Bezel width (top) | 1.63 cm |
| Bezel width (side) | 1.63 cm |
| Bezel width (bottom) | 1.63 cm |
| OPS module slot | No |
