Description
Long Range CCD Handheld Barcode Scanner, USB, 500mm Scan Depth, Cable 1.5m, Max Ambient Light 10,000 lux (sunlight), Black, Three Year Warranty
The Manhattan Long Range CCD Barcode Scanner delivers basic, high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The scan engine features no moving parts for years of reliable service reading popular 1D barcodes including UPC, EAN, ASCII, MSI/PLESSEY, GS1 DataBar and more. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application where it appears as if it were manually typed or directly keyed into the computer. Its versatile switchable USB or PS/2 cable interface integrates with most PCs without an external power supply. With a scan rate of 500 scans per second and an accurate read range of up to 50 cm (20 in.), this model offers an effective and efficient, all-purpose daily scanning solution for less demanding point-of-sale, office and other low ambient light applications to minimize manual data entry, speed transactions and reduce errors.
Key Features
- Helps speed data entry, reduce errors and improve efficiency – ideal for retail transactions and automated processes
- Keyboard Wedge Decoder displays data as if directly entered from keyboard
- Wide scan field provides quick, accurate reads with up to 500 scans per second up to 50 cm (20 in.) away
- Detects many popular symbologies including UPC, EAN and GS1 DataBar
- Switchable interface integrates with most PCs
- Easy to install and use without software or special training
- Three-Year Warranty
Description
Improve speed, accuracy and productivity._x000D_The Manhattan Long Range CCD Barcode Scanner delivers basic, high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The scan engine features no moving parts for years of reliable service reading popular 1D barcodes including UPC, EAN, ASCII, MSI/PLESSEY, GS1 DataBar and more. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application where it appears as if it were manually typed or directly keyed into the computer. Its versatile switchable USB or PS/2 cable interface integrates with most PCs without an external power supply. With a scan rate of 500 scans per second and an accurate read range of up to 50 cm (20 in.), this model offers an effective and efficient, all-purpose daily scanning solution for less demanding point-of-sale, office and other low ambient light applications to minimize manual data entry, speed transactions and reduce errors.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, Industrial 2 of 5, Interleaved 2 of 5, JAN, MSI, Plessey, Telepen |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Working distance | 50 cm |
| Sensor type | CCD |
| Scanner type | 1D |
| Read rate (max) | 500 reads/s |
| Maximum scan width | 10 cm |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Cable length | 1.5 m |
| Standard interfaces | USB |
| Performance | |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| Product colour | Black |
| Certification | FCC, CE, USB |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Design | |
| Type | Handheld bar code reader |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| Product colour | Black |
| Certification | FCC, CE, USB |
| Power | |
| Power consumption | 150 mA |
| Power source type | USB |
| Input voltage | 5 V |
| Weight & dimensions | |
| Width | 89 mm |
| Depth | 177.5 mm |
| Height | 19 mm |
| Weight | 440 g |
| Technical details | |
| Type | Handheld bar code reader |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| Product colour | Black |
| Certification | FCC, CE, USB |
| Harmonized System (HS) code | 84716070 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
