LevelOne 16-Port Fast Ethernet PoE Switch, 240W, 802.3at/af PoE

16 x 10/100Base-TX RJ-45 PoE, 250W, 3.2Gbps, 10/100Mbps, MAC 4K, IEEE 802.3/u/x/af/at

Description

The LevelOne FEP-1611 provides 16 x 10/100Mbps ports with IEEE 802.3at PoE plus supported. This switch is IEEE 802.3at/af compliant, and provides power and data over a single Ethernet cable to any PoE device, with total power budget of 240W, up to 30W per port. Ideal for desktops and it is also 19-inch rack-mountable, which provides convenient and flexible installation. The FEP-1611 is designed for small-to-median businesses that prefer an affordable solution for PoE deploying infrastructure.

- IEEE 802.3af/at PoE compliant to simplify deployment and installation
- Auto-detection and protection of non-standard PoE devices
- Supports 4K MAC address auto-learning and auto-aging
- 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
- 19-inch metal housing
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Total PoE power budget: 240W, up to 30W per port

Specifications

Ports & interfaces
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Performance
Stackable	No
Auto-negotiation	Yes
Buffer size	160 KB
Harmonized System (HS) code	85176990
Technical details
Product colour	Grey
Stackable	No
Rack mounting	Yes
Management features
Switch type	Unmanaged
Network
Cable types supported	Cat5
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Full duplex	Yes
Auto MDI/MDI-X	Yes
10G support	No
Auto-negotiation	Yes
Data transmission
Packet forwarding rate (100 Mbps)	148000 pps
Packet forwarding rate (10 Mbps)	14880 pps
MAC address table	4096 entries
Switching capacity	3.2 Gbit/s
Store-and-forward	Yes
Security
MAC address filtering	Yes
Certificates
Certification	FCC, CE, RoHS
Design
Country of origin	Taiwan
Product colour	Grey
Stackable	No
LED indicators	Activity, LAN, PoE, Power
Certification	FCC, CE, RoHS
Rack mounting	Yes
Indication
LED indicators	Activity, LAN, PoE, Power
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Input current	5 A
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	16
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	480 mm
Depth	200 mm
Height	44 mm
Weight	2.85 kg
Packaging data
Package type	Box
Quick start guide	Yes
Package width	540 mm
Package depth	260 mm
Package height	96 mm
Package weight	4.75 kg
Cables included	AC
Logistics data
Harmonized System (HS) code	85176990
Packaging content
Quick start guide	Yes
Cables included	AC
Other features
Country of origin	Taiwan
