Description
Data Collector, 2D, CMOS, 752 x 480 pixels, Bluetooth, IP54, w/Battery
The PX20 is supplied as a ready to go functional kit including a USB cable and lanyard. With its unique ergonomic design and weighing only 40 grams the PX20 is perfectly suited to being worn around the user’s neck with the lanyard supplied. Besides a modern and well thought-out design the PX20 has a drop resistance to 1.8 meters (no need for a special protection cover) and is IP 54. The PX20 is modern, fully functional and very durable, perfect for outdoor operations.
Description
The PX20 is the smallest programmable 2D Bluetooth data collector. With a fast integrated 2D CMOS scanner and when fully charged, offering operating times of up to 35 hours. In occasions where Bluetooth is not provided, access by the USB port enables (cabled) data transfer to any USB device.The PX20 is supplied as a ready to go functional kit including a USB cable and lanyard. With its unique ergonomic design and weighing only 40 grams the PX20 is perfectly suited to being worn around the user’s neck with the lanyard supplied. Besides a modern and well thought-out design the PX20 has a drop resistance to 1.8 meters (no need for a special protection cover) and is IP 54. The PX20 is modern, fully functional and very durable, perfect for outdoor operations.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), MSI, Plessey, Telepen, Trioptic, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Codablock, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417 |
| Tilt reading angle | 0 - 360° |
| Sensor type | CMOS |
| Pitch reading angle | -50 - 50° |
| Ports & interfaces | |
| Connectivity technology | Wireless |
| Bluetooth version | 2.1+EDR |
| Standard interfaces | Bluetooth, USB |
| Performance | |
| LED indicators | Yes |
| Keys quantity | 2 keys |
| Housing material | ABS synthetics |
| Built-in display | No |
| RAM capacity | 0.096 MB |
| Built-in processor | RX62N 32-bit MCU |
| International Protection (IP) code | IP54 |
| Internal memory | 0.512 MB |
| Product colour | Black, White |
| Certification | CE, FCC, VCCI, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II, IEC62471, EN60950-1, IEC60950-1, EN55022, EN55024 |
| Buzzer | Yes |
| Design | |
| Type | Handheld bar code reader |
| LED indicators | Yes |
| Keys quantity | 2 keys |
| Housing material | ABS synthetics |
| International Protection (IP) code | IP54 |
| Product colour | Black, White |
| Certification | CE, FCC, VCCI, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II, IEC62471, EN60950-1, IEC60950-1, EN55022, EN55024 |
| Power | |
| Power source type | Battery |
| Battery life | 20 h |
| Weight & dimensions | |
| Width | 34 mm |
| Depth | 15 mm |
| Height | 34 mm |
| Weight | 40 g |
| Technical details | |
| Type | Handheld bar code reader |
| LED indicators | Yes |
| Keys quantity | 2 keys |
| Housing material | ABS synthetics |
| Built-in display | No |
| RAM capacity | 0.096 MB |
| Built-in processor | RX62N 32-bit MCU |
| International Protection (IP) code | IP54 |
| Internal memory | 0.512 MB |
| Product colour | Black, White |
| Certification | CE, FCC, VCCI, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II, IEC62471, EN60950-1, IEC60950-1, EN55022, EN55024 |
| Buzzer | Yes |
| Compliance certificates | RoHS |
| Packaging data | |
| Cables included | USB |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Packaging content | |
| Cables included | USB |
