Description
LX Sit-Stand Desk Arm, Capacity 7–25 lbs / 3.2–11.3 kg
The LX provides unparalleled range of motion, being able to accommodate a user’s sitting or standing posture—features 20 inches (51 cm) of vertical adjustment and 62 inches (157 cm) of side-to-side adjustment.
- 20-inch (51 cm) height range allows users to move between sitting and standing positions while they interact with the display
- Extends LCD up to 33" (84 cm); push your display out of the way when not in use
- Increase viewing comfort—help reduce eye, back and neck strain
- Upgrade LCD monitors and TVs with improved ergonomic adjustment
- CF motion technology provides premium ease-of-use adjustment
- Cable management clips on the under side of the arm route and hide cords
- Ideal for space-constrained spaces—folds to within 4.5" (12 cm) of back of desk in storage position
- Secure installation—locking connections between arm, extension and base
- Passes Ergotron’s 10,000-cycle motion test, which ensures a minimum of five years trouble-free height adjustment
Key Features
- Comfortable fit
- More motion
- Saves space
- Large extension
- Sleek build
- Quality design
Reasons To Buy
Comfortable fit
Offers full monitor movement and improved ergonomicsMore motion
20" of height adjustment lets you work sitting or standingSaves space
Folds within inches of the back of your desk when not in useLarge extension
Screens extend out 33" with 62" of side-to-side motionSleek build
Streamlined look enhances your work areaQuality design
Built for thousands of movements by passing 10,000-cycle testDescription
This versatile arm can be used in a variety of applications: attach a smaller monitor for use within a sit-stand workstation or position a large display up to 25 lbs (11.3 kg) wherever you want it.The LX provides unparalleled range of motion, being able to accommodate a user’s sitting or standing posture—features 20 inches (51 cm) of vertical adjustment and 62 inches (157 cm) of side-to-side adjustment.
- 20-inch (51 cm) height range allows users to move between sitting and standing positions while they interact with the display
- Extends LCD up to 33" (84 cm); push your display out of the way when not in use
- Increase viewing comfort—help reduce eye, back and neck strain
- Upgrade LCD monitors and TVs with improved ergonomic adjustment
- CF motion technology provides premium ease-of-use adjustment
- Cable management clips on the under side of the arm route and hide cords
- Ideal for space-constrained spaces—folds to within 4.5" (12 cm) of back of desk in storage position
- Secure installation—locking connections between arm, extension and base
- Passes Ergotron’s 10,000-cycle motion test, which ensures a minimum of five years trouble-free height adjustment
Specifications
| Mounting | |
|---|---|
| Number of displays supported | 1 |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Maximum weight capacity | 11.3 kg |
| Ergonomics | |
| Cable management | Yes |
| Height adjustment | Yes |
| Tilt angle range | -5 - 70° |
| Angle of rotation | 360° |
| Pan range | 0 - 360° |
| Design | |
| Product colour | Metallic |
| Technical details | |
| Mounting type | Desk |
| Product colour | Metallic |
| Cable management | Yes |
| Weight & dimensions | |
| Depth | 120 mm |
| Weight | 8.9 kg |
| Package weight | 10 kg |
| Packaging data | |
| Package weight | 10 kg |
| Package dimensions (WxDxH) | 380 x 190 x 640 mm |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
| Other features | |
| Package dimensions (WxDxH) | 380 x 190 x 640 mm |
| Mounting type | Desk |
