2.4 GHz, 10/100 Ethernet RJ-45, 32 MB SDRAM, 8 MB Flash, 5+ km, PoE
Description
Compact CPE Design
The NanoStationM features the CPE design that expanded the global Wireless ISP industry.
Plug and Play Installation
The NanoStation M requires no tools for assembly; only a single wrench is required for pole-mounting.
Versatile Application Use
The NanoStation M can be deployed for Point-to-Point (PtP) bridging, wireless connectivity to a video surveillance system, or use as an airMAX CPE.
Dual Ethernet Connectivity
With software-enabled PoE output, the secondary Ethernet port can power an external device, such as a PoE security camera, for seamless IP video integration.
Advanced Software Technology
Ubiquiti’s airMAX technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
Window/Wall Mounting Kit
Use the NanoStation Mount to quickly mount the NanoStationM on a window or wall. 180° vertical or horizontal adjustment allows for custom positioning.
Specifications
| Data transmission |
|---|
| Wi-Fi data rate (max) |
150 Mbit/s |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Maximum data transfer rate |
150 Mbit/s |
| Performance |
|---|
| 2.4 GHz |
Yes |
| Wi-Fi data rate (max) |
150 Mbit/s |
| Frequency band |
2.412-2.462 GHz |
| Networking standards |
IEEE 802.3, IEEE 802.3u |
| Maximum outdoor range |
10000 m |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Certification |
RoHS |
| Maximum data transfer rate |
150 Mbit/s |
| Internal memory |
32 MB |
| Flash memory |
8 MB |
| Built-in processor |
Yes |
| Processor model |
Qualcomm Atheros |
| Processor frequency |
400 MHz |
| Processor architecture |
MIPS 24Kc |
| Wireless LAN features |
|---|
| Frequency band |
2.412-2.462 GHz |
| Maximum outdoor range |
10000 m |
| Network |
|---|
| Internal |
No |
| Networking standards |
IEEE 802.3, IEEE 802.3u |
| Certificates |
|---|
| Certification |
RoHS |
| Memory |
|---|
| Internal memory |
32 MB |
| Flash memory |
8 MB |
| Features |
|---|
| 2.4 GHz |
Yes |
| Wi-Fi data rate (max) |
150 Mbit/s |
| Frequency band |
2.412-2.462 GHz |
| Networking standards |
IEEE 802.3, IEEE 802.3u |
| Maximum outdoor range |
10000 m |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Maximum data transfer rate |
150 Mbit/s |
| Internal memory |
32 MB |
| Flash memory |
8 MB |
| Built-in processor |
Yes |
| Processor model |
Qualcomm Atheros |
| Processor frequency |
400 MHz |
| Processor architecture |
MIPS 24Kc |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power consumption (typical) |
5.5 W |
| Power over Ethernet (PoE) |
Yes |
| Input current |
0.5 A |
| AC input voltage |
24 V |
| Design |
|---|
| Housing material |
Plastic |
| Product colour |
White |
| Internal |
No |
| LED indicators |
Yes |
| Certification |
RoHS |
| Antenna |
|---|
| Antenna gain level (max) |
8 dBi |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Processor |
|---|
| Built-in processor |
Yes |
| Indication |
|---|
| LED indicators |
Yes |
| Weight & dimensions |
|---|
| Width |
80 mm |
| Depth |
31 mm |
| Weight |
180 g |
| Height |
163 mm |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-30 - 75 °C |
