Description
48VDC @ 0.5A, RJ-45
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.
Description
Device ProtectionPoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.
Specifications
| Network | |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Power over Ethernet (PoE) voltage | 48 V |
| Features | |
| Surge protection | Yes |
| Product colour | Black |
| LED indicators | No |
| Certification | IEC 60950-1:2005+A1 UL60950‐1 EN55022:2010, EN55024:2010 FCC Class B |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Power | |
| Output current | 0.5 A |
| Power over Ethernet (PoE) voltage | 48 V |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Input current | 0.4 - 0.6 A |
| Certificates | |
| Certification | IEC 60950-1:2005+A1 UL60950‐1 EN55022:2010, EN55024:2010 FCC Class B |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 35 - 95% |
| Weight & dimensions | |
| Weight | 158.5 g |
| Width | 59.9 mm |
| Depth | 91.8 mm |
| Height | 33 mm |
| Technical details | |
| Power over Ethernet (PoE) | Yes |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Input current | 0.4 - 0.6 A |
| Ethernet interface type | Gigabit Ethernet |
| Harmonized System (HS) code | 85044095 |
| Indication | |
| LED indicators | No |
| Logistics data | |
| Harmonized System (HS) code | 85044095 |
