Description
Pro VGA + Audio to HDMI 1M
a stand-alone converter, the cable requires no additional power supply, and provides
a compact connectivity solution ideal for environments with a limited space. Coupled
with its compatibility with resolutions of up to 1920x1080p, the cable is designed to meet
the demands of a Pro AV system integration.
Key Features
- Supports EDID
- Supports resolutions up to Full HD 1920*1080p@60Hz
- Tinned copper conductor
- Triple shielding in cable and extra shielding in connector
- High flexibility
- USB cable for power supply
- Embedded analog audio to HDMI
Description
VGA + Audio to HDMI adapter cable. This cable can be used to connect a VGA+audio source to an HDMI input device. Unlikea stand-alone converter, the cable requires no additional power supply, and provides
a compact connectivity solution ideal for environments with a limited space. Coupled
with its compatibility with resolutions of up to 1920x1080p, the cable is designed to meet
the demands of a Pro AV system integration.
Specifications
| Features | |
|---|---|
| Converter type | Active video converter |
| Audio connector type | 3.5 mm (1/8") |
| Audio connector | Yes |
| HDMI version | 1.4 |
| Product colour | Black |
| Cable length | 1 m |
| Connector 1 | HDMI |
| Connector 2 | VGA (D-Sub) + 3.5mm + USB Type-A |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Cable material | Copper |
| Jacket material | Polyvinyl chloride (PVC) |
| AWG wire size | 28 |
| 3D | No |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| HDCP | Yes |
| Plug and Play | Yes |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Dual Link DVI | No |
| Linux operating systems supported | Yes |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.2 |
| High Dynamic Range (HDR) supported | No |
| Supported audio channels | 7.1 |
| Cable colour | Black |
| Technical details | |
| Cable colour | Black |
| Harmonized System (HS) code | 84733080 |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Weight | 100 g |
| Package width | 185 mm |
| Package depth | 127 mm |
| Package height | 36 mm |
| Package weight | 142 g |
| Packaging data | |
| Package width | 185 mm |
| Package depth | 127 mm |
| Package height | 36 mm |
| Package weight | 142 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Other features | |
| Supported resolutions | 1080P@60Hz |
| Cable colour | Black |
