Description
Wireless bluetooth, IP42, CCD (1D), black
Applications
This product is used in service environments, kiosks, store counters, warehouses, administrative services or tasks and retail. The OPC-3301i has a modern classic and clean look that fits perfectly on a counter or desk where no cables are desired. The CCD is more resistant to breaking since it has no oscillating mirrors.
How we describe the OPC-3301i
The OPC-3301i has a strong CCD scan engine and can read low-contrast, high density and regular barcodes. The scanner is Apple MFi certified which means it can connect to your iPad, iPhone or iPad. The CCD engine scans up to 300 scans per second which will improve productivity greatly. The scanners design is ergonomic with a comfortable scanning experience in mind. The scanner weighs only 120 grams and is IP 42 resistant. This is the CCD scanner version of the OPI-3301i
The operator of this scanner does not require any training in detail, the minimum guidance is sufficient. This device is a scanner that looks good in any store, office or warehouse.
Key Features
- 1D Scanning
- Bluetooth connection
- Lightweight
- Plug and play
Description
The OPC-3301i is a compact wireless handheld CCD scanner that uses Bluetooth for real-time data transfer. It is easy to use and makes the user mobile while scanning. It can be connected to any Apple product due to the MFi certification. The OPC-3301i is a CCD scanner well worth its name.Applications
This product is used in service environments, kiosks, store counters, warehouses, administrative services or tasks and retail. The OPC-3301i has a modern classic and clean look that fits perfectly on a counter or desk where no cables are desired. The CCD is more resistant to breaking since it has no oscillating mirrors.
How we describe the OPC-3301i
The OPC-3301i has a strong CCD scan engine and can read low-contrast, high density and regular barcodes. The scanner is Apple MFi certified which means it can connect to your iPad, iPhone or iPad. The CCD engine scans up to 300 scans per second which will improve productivity greatly. The scanners design is ergonomic with a comfortable scanning experience in mind. The scanner weighs only 120 grams and is IP 42 resistant. This is the CCD scanner version of the OPI-3301i
The operator of this scanner does not require any training in detail, the minimum guidance is sufficient. This device is a scanner that looks good in any store, office or warehouse.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Code 128, Code 39, Code 93, GS1 DataBar Expanded, GS1-128 (UCC/EAN-128), Interleaved 2 of 5, Plessey, S-Code, Telepen, Trioptic |
| Yaw reading angle | -65 - 65° |
| Tilt reading angle | 0 - 25° |
| Sensor type | CCD |
| Scanner type | 1D |
| Read rate (max) | 300 reads/s |
| Pitch reading angle | -50 - 50° |
| Ports & interfaces | |
| Wireless range | 10 m |
| Connectivity technology | Wireless |
| Bluetooth version | 2.1+EDR |
| Standard interfaces | Bluetooth |
| Performance | |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| Built-in display | No |
| RAM capacity | 1 MB |
| International Protection (IP) code | IP42 |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Buzzer | Yes |
| Design | |
| Type | Handheld bar code reader |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| International Protection (IP) code | IP42 |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Power | |
| Power consumption | 15 mA |
| Power source type | Battery |
| Battery life | 72 h |
| Charging time | 3 h |
| Battery voltage | 3.7 V |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 1100 mAh |
| Weight & dimensions | |
| Width | 113 mm |
| Depth | 56 mm |
| Height | 132 mm |
| Weight | 127 g |
| Package width | 130 mm |
| Package depth | 32 mm |
| Package height | 116 mm |
| Package weight | 41 g |
| Technical details | |
| Type | Handheld bar code reader |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| Built-in display | No |
| RAM capacity | 1 MB |
| International Protection (IP) code | IP42 |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Buzzer | Yes |
| Harmonized System (HS) code | 84716070 |
| Packaging data | |
| Charging base | No |
| Package width | 130 mm |
| Package depth | 32 mm |
| Package height | 116 mm |
| Package weight | 41 g |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 20 - 85% |
| Packaging content | |
| Charging base | No |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
