Description
OPI-3301i, 2D, Bluetooth
- Wireless 2D CMOS imager scanner that rapidly scans and decodes 1D and 2D barcodes at 60 Frames Per Second (FPS)
- Supports Apple MFi, SPP and HID Bluetooth profiles for added flexibility
- Memory: 1MB SDRAM, 1MB Flash ROM
- Small form factor: 2.20" x 5.32" x 4.45" (WxHxD) and 4.5 ounces including battery
- Extremely durable: IP42 rating against dust and moisture and survives 5 ft drop to concrete
- Charges via cradle (CHG-3201—sold separately), Bluetooth dongle available (OPA-3201)
- Backed by a two year warranty
Description
The Opticon OPI-3301i features a high speed, 2D Imager barcode scanner and a lightweight, ergonomic design that is perfect for all day, everyday use in a wide variety of industries including retail, healthcare, warehousing and distribution, and transportation and logistics. The cordless, cable-free freedom of Bluetooth® wireless communication offers the ability to roam away from the host device, which improves productivity and scanning convenience. The OPI-3301i is built to survive and thrive due to its IP42 sealing rating against dust and moisture and 5 foot drop specification. The scanner is also Apple MFI certified for the added ease of connecting and communicating with iOS host devices. Product highlights include:- Wireless 2D CMOS imager scanner that rapidly scans and decodes 1D and 2D barcodes at 60 Frames Per Second (FPS)
- Supports Apple MFi, SPP and HID Bluetooth profiles for added flexibility
- Memory: 1MB SDRAM, 1MB Flash ROM
- Small form factor: 2.20" x 5.32" x 4.45" (WxHxD) and 4.5 ounces including battery
- Extremely durable: IP42 rating against dust and moisture and survives 5 ft drop to concrete
- Charges via cradle (CHG-3201—sold separately), Bluetooth dongle available (OPA-3201)
- Backed by a two year warranty
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Sensor type | CMOS |
| Scanner type | 2D |
| Optical sensor resolution (W x H) | 752 x 480 pixels |
| Ports & interfaces | |
| Wireless range | 10 m |
| Connectivity technology | Wireless |
| Bluetooth version | 2.1+EDR |
| Standard interfaces | Bluetooth |
| Performance | |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Design | |
| Type | Handheld bar code reader |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Power | |
| Power consumption | 15 mA |
| Power source type | Battery |
| Battery life | 72 h |
| Charging time | 3 h |
| Battery voltage | 3.7 V |
| Battery capacity | 1100 mAh |
| Weight & dimensions | |
| Width | 56 mm |
| Depth | 113 mm |
| Height | 135 mm |
| Weight | 132 g |
| Package width | 60 mm |
| Package depth | 28 mm |
| Package height | 56 mm |
| Package weight | 18 g |
| Technical details | |
| Type | Handheld bar code reader |
| Product colour | Black |
| Certification | CE, FCC, VCCI, MFi, RoHS, IEC 62471, IEC 60950-1 |
| Harmonized System (HS) code | 84716070 |
| Packaging data | |
| Package width | 60 mm |
| Package depth | 28 mm |
| Package height | 56 mm |
| Package weight | 18 g |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 20 - 85% |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
