Description
Rack PDU, Basic, 0U/1U, 120-240V/15A, (8) C13, Black
Description
The APC by Schneider Electric Basic Rack Power Distribution Unit (PDU) distributes power to devices in the rack.Specifications
| Design | |
|---|---|
| PDU types | Basic |
| Mounting | Horizontal/Vertical |
| Product colour | Black |
| Certification | VDE, CE |
| Rack capacity | 0U/1U |
| Ports & interfaces | |
| AC outlets quantity | 8 AC outlet(s) |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| Features | |
| Cable length | 3.65 m |
| Certification | VDE, CE |
| Ergonomics | |
| Cable length | 3.65 m |
| Power | |
| Maximum power | 2300 W |
| Nominal input voltage | 230 V |
| Nominal output voltage | 120 - 240 V |
| Maximum current | 10 A |
| Maximum input current per phase | 10 A |
| Load capacity | 2300 VA |
| AC input frequency | 50 - 60 Hz |
| Certificates | |
| Certification | VDE, CE |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -15 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Compliance certificates | RoHS |
