Description
2TB, 6Gb/s, SAS, 7200 rpm, 64MB
- Meets regulatory data security compliance requirements and is FIPS 140-2 Validated™ to protect Sensitive but Unclassified and Protected class data.
- Fifth-generation, capacity-optimized nearline drive designed for 24x7 enterprise reliability.
- SAS-based, end-to-end data integrity and enhanced error correction for accurate data storage.
- Best-in-class enhanced rotational vibration tolerance ensures consistent bulk data performance.
- Improved power and cooling efficiencies with low power consumption and enhanced PowerChoice™ technology.
- Multi-drive firmware maximized for enterprise system availability.
- Robust performance with dual processor and ramp load technologies.
- Self-Encrypting Drive (SED) models with Seagate Instant Secure Erase cut IT drive retirement costs while securely protecting data where it lives - on the drive.
Description
- Industry’s highest capacity enterprise drive for sustaining demanding data growth.- Meets regulatory data security compliance requirements and is FIPS 140-2 Validated™ to protect Sensitive but Unclassified and Protected class data.
- Fifth-generation, capacity-optimized nearline drive designed for 24x7 enterprise reliability.
- SAS-based, end-to-end data integrity and enhanced error correction for accurate data storage.
- Best-in-class enhanced rotational vibration tolerance ensures consistent bulk data performance.
- Improved power and cooling efficiencies with low power consumption and enhanced PowerChoice™ technology.
- Multi-drive firmware maximized for enterprise system availability.
- Robust performance with dual processor and ramp load technologies.
- Self-Encrypting Drive (SED) models with Seagate Instant Secure Erase cut IT drive retirement costs while securely protecting data where it lives - on the drive.
Specifications
| Hard drive | |
|---|---|
| Data transfer rate | 6 Gbit/s |
| Write seek time | 9.5 ms |
| Read seek time | 8.5 ms |
| Average latency | 4.16 ms |
| Mean time between failures (MTBF) | 1200000 h |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| HDD capacity | 2 TB |
| Features | |
| Interface | SAS |
| Write seek time | 9.5 ms |
| Read seek time | 8.5 ms |
| Average latency | 4.16 ms |
| Mean time between failures (MTBF) | 1200000 h |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| HDD capacity | 2 TB |
| Storage drive buffer size | 64 MB |
| Power | |
| Power consumption (typical) | 10.90 W |
| Power consumption (idle) | 6.20 W |
| Start-up current | 1.71 A |
| Operating voltage | 5 / 12 V |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Technical details | |
| Harmonized System (HS) code | 84717050 |
| Interface | SAS |
| Mean time between failures (MTBF) | 1200000 h |
| Internal | Yes |
| Security | |
| Security algorithms | FIPS 140-2 |
| Weight & dimensions | |
| Width | 101.8 mm |
| Weight | 655 g |
| Height | 26.1 mm |
| Depth | 147 mm |
| Logistics data | |
| Harmonized System (HS) code | 84717050 |
| Other features | |
| Interface | SAS |
| Security algorithms | FIPS 140-2 |
| Data transfer rate | 6 Gbit/s |
| Internal | Yes |
