4x4 MIMO, 2.4/ 5 GHz, RJ-45, Dual WAN, 1x USB 3.0, 1x USB 2.0, SD/SDXC/SDHC, 280 x 169 x 77 mm, 700 g
Description
Blazing-fast Wi-Fi with up to 2.53Gbps combined wireless bandwidth to supercharge your network. RT2600ac is a powerful wireless router for homes and small offices seeking to work and play smarter, featuring comprehensive VPN solutions, enhanced security, and flexible media and file sharing capabilities.
Engineered for performance
Supporting MU-MIMO and the latest 802.11ac wave 2 standard, RT2600ac enables up to 800Mbps and 1733Mbps on the 2.4GHz and 5GHz radios respectively. Reach 2Gbps combined bandwidth with Dual WAN, and easily optimize your network with minimal performance loss even with Layer 7 traffic control.
CPU
1.7GHz Dual Core
Powerful Wi-Fi
Quad Stream, Dual Band
AC2600, Wave 2
With MU-MIMO & Beamforming
Layer 4 & 7
Hardware Acceleration Engine
Top software experience
Synology Router Manager (SRM) powers the RT2600ac to keep things simplified yet extensively tunable. Easily monitor and adjust your network, even on mobile devices with DS router.
VPN Plus
Keep your network’s internal services and resources hardened against direct access while still allowing work from home or a remote location with VPNs. Easily deploy a wide range of VPN solutions and manage access permissions and bandwidth allowances.
Synology SSL VPN
Secure and fast, Synology’s SSL VPN solution requires minimal setup on Windows, Ubuntu, and iOS, making rapid deployment as easy as logging into a web portal.
WebVPN
Clientless WebVPN for centralized access to company intranets and web backends. Easily login from anywhere with only a browser for a secured connection.
Comprehensive protocols
Additionally supports SSTP, OpenVPN, L2TP/IPSec, and PPTP VPN server options to satisfy your specific network requirements.
Powerful connectivity management
SRM delivers easy-to-use connectivity management tools to ensure your network always runs smoothly.
Smart WAN
SRM’s Smart WAN capability on the RT2600ac supports 2Gbps Dual WAN combined bandwidth when multiple connections are established1. If one of the connections goes offline due to ISP or cable problems, traffic can failover to the other interface. Load balancing can be used in addition to failover, spreading traffic across both interfaces. Policy route allows traffic routing based on destination or source address.
Smart Connect
Not sure which devices should connect to the 2.4 GHz and 5GHz bands? With Synology’s Smart Connect, devices are connected to the most appropriate band automatically, letting users experience simplified management without worry about range or speed issues.
Content filtering & monitoring
Application Layer QoS and Traffic Report
Application Layer or Layer 7, Quality of Service control shows the bandwidth consumed by individual applications and devices. Restrict the amount of bandwidth for specific applications, without affecting the rest, and generate traffic usage reports sorted by application and device.
Intelligent Web Filtering and Parental controls
Instead of traditional URL-based web filtering, SRM does so during DNS lookup. Easily block out thousands of sites with built-in Google SafeSearch integration and a constantly updated database of customizable website categories.
Stay protected
In addition to standard security tools like denial-of-service protection and firewall management, SRM delivers innovative tools and features to help protect your network from outside attacks.
Intrusion Prevention
Intrusion Detection System analyzes network traffic and logs all intrusion attempts, allowing for fine-tuning of your firewall rules with minimal performance impact. Intrusion Prevention System additionally blocks suspicious traffic based on customizable rules.
Security Advisor & QualysGuard
Monitor and check settings and system files for security issues and automatically apply recommended fixes. Synology utilizes the industry leading Qualysguard platform to detect and enhance security across all Synology operating systems.
Continuously updated
New vulnerabilities and exploits are discovered in the wild every day. Synology is committed to providing fast updates to keep device security up to date for maximum protection. SRM can automatically perform upgrades on a schedule for maximum convenience.
Manage, sync, back up, and more
With an external storage device or SD card, RT2600ac can become a private cloud server with Synology’s Cloud Station Suite, allowing easy access to files, photos, and even backups for multiple devices. Mac users also enjoy Time Machine compatibility. Connect devices with USB 3.0 to take advantage of RT2600ac’s powerful connectivity.
Add-on Packages
SRM’s modular design allows for a tailored and optimized experience to suit your needs.
Wi-Fi and DLNA Certified
Wave 2 ac and DLNA certified for maximum compatibility with your other devices.
Synology QuickConnect & DDNS
Simplified access management and connectivity.
Specifications
| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| DSL features |
|---|
| DSL WAN |
Yes |
| Mobile network |
|---|
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| 3G |
No |
| 4G |
No |
| Network |
|---|
| Wake-on-LAN ready |
Yes |
| Guest access |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| VPN support |
PPTP, OpenVPNTM, L2TP IPSec |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Protocols |
|---|
| DMZ support |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Supported network protocols |
IPv4, IPv6, FTP, FTP SSL / TLS, SFTP |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Management features |
|---|
| Universal Plug and Play (UPnP) |
Yes |
| WPS push button |
Yes |
| Web-based management |
Yes |
| Wake-on-LAN ready |
Yes |
| Reset button |
Yes |
| Security |
|---|
| VPN support |
PPTP, OpenVPNTM, L2TP IPSec |
| Security algorithms |
WEP, WPA, WPA2, WPS |
| MAC address filtering |
Yes |
| Guest access |
Yes |
| Firewall security |
IPv4, IPv6 |
| Firewall |
Yes |
| DoS attack prevention |
Yes |
| DMZ support |
Yes |
| Filtering |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Performance |
|---|
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Processor frequency |
1700 MHz |
| Processor cores |
2 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Compatible memory cards |
SD, SDHC, SDXC |
| Built-in processor |
Yes |
| Memory card slot(s) |
Yes |
| Certificates |
|---|
| Certification |
RoHS, CE, FCC, NCC, RCM |
| Digital Living Network Alliance (DLNA) certified |
Yes |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Wireless LAN features |
|---|
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
1733 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) |
800 Mbit/s |
| WLAN data transfer rate (second band) |
1733 Mbit/s |
| Ports & interfaces |
|---|
| USB port |
Yes |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
5 |
| DC-in jack |
Yes |
| Compatible memory cards |
SD, SDHC, SDXC |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Memory card slot(s) |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| On/off switch |
Yes |
| Product colour |
Black |
| Software |
|---|
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Mac compatibility |
Yes |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Antenna |
|---|
| Antenna design |
External |
| Antennas quantity |
4 |
| Antenna gain level (max) |
4.5 dBi |
| Features |
|---|
| Processor frequency |
1700 MHz |
| Processor cores |
2 |
| Certification |
RoHS, CE, FCC, NCC, RCM |
| Built-in processor |
Yes |
| Harmonized System (HS) code |
85176990 |
| Power |
|---|
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
5 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 5000 m |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Mac compatibility |
Yes |
| Weight & dimensions |
|---|
| Width |
280 mm |
| Weight |
700 g |
| Height |
77 mm |
| Depth |
169 mm |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
