Description
Wall Mount for TV & Monitors (Full Motion), For screens 13" to 42", VESA compatability: all between 75x75mm and 200x200mm - check the dimensions of the four mounting holes on back of screen to ensure it fits, Max 20kg, Black, Bracket
Overcome an odd floor plan, annoying glare or awkward furniture placement that can limit the enjoyment of your flat-panel TV. The Manhattan Universal Flat-Panel TV Articulating Wall Mount folds nearly flat against the wall and safely extends on a strong, double-jointed arm to help you achieve prime viewing positions from almost anywhere in the room. VESA-compliant and constructed of quality materials, this articulating wall mount fits a range of display sizes for a secure and confident above-the-floor TV installation. It's the perfect fit for mounting a TV in your living room, bedroom or den, as well as for commercial uses in hotels, classrooms, conference rooms, for digital signage and more. Wherever you install it, the Manhattan Universal Flat-Panel TV Articulating Wall Mount puts the best TV viewing experience front and centre.
Key Features
- Securely holds one flat-panel television or monitor
- Optimize views with +5° to -12° tilt, ±45° swivel and ±3° level adjustment
- Extends TV up to 27.3 cm (10.75 in.) from wall
- Solid steel construction
- Easy installation ideal for home, office and commercial applications
- Removable VESA plate enables fast and easy attachment of monitor or TV
- Built-in cable-management system
- Meets VESA standards – supports TVs from 13” to 42" up to 20 kg (44 lbs.)
- Lifetime Warranty
Description
A TV wall mount to fit almost any spaceOvercome an odd floor plan, annoying glare or awkward furniture placement that can limit the enjoyment of your flat-panel TV. The Manhattan Universal Flat-Panel TV Articulating Wall Mount folds nearly flat against the wall and safely extends on a strong, double-jointed arm to help you achieve prime viewing positions from almost anywhere in the room. VESA-compliant and constructed of quality materials, this articulating wall mount fits a range of display sizes for a secure and confident above-the-floor TV installation. It's the perfect fit for mounting a TV in your living room, bedroom or den, as well as for commercial uses in hotels, classrooms, conference rooms, for digital signage and more. Wherever you install it, the Manhattan Universal Flat-Panel TV Articulating Wall Mount puts the best TV viewing experience front and centre.
Specifications
| Mounting | |
|---|---|
| Mounting type | Wall |
| Minimum screen size | 33 cm (13") |
| Panel mounting interface | 75 x 75,100 x 100,200 x 100,200 x 200 |
| Number of displays supported | 1 |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 200 x 200 mm |
| Maximum screen size | 106.7 cm (42") |
| Maximum weight capacity | 20 kg |
| Suitable for computer monitor | Yes |
| Ergonomics | |
| Cable management | Yes |
| Tilt angle range | -12 - 5° |
| Swivel angle range | -45 - 45° |
| Distance to the wall (min) | 6 cm |
| Distance to the wall (max) | 27.3 cm |
| Tilt adjustment | Yes |
| Technical details | |
| Cable management | Yes |
| Number of displays supported | 1 |
| Distance to the wall (min) | 6 cm |
| Distance to the wall (max) | 27.3 cm |
| Product colour | Black |
| Mounting type | Wall |
| Design | |
| Cable management | Yes |
| Product colour | Black |
| Housing material | Steel |
| Packaging content | |
| Manual | Yes |
| Weight & dimensions | |
| Width | 220 mm |
| Height | 220 mm |
| Weight | 1.31 kg |
| Depth (max) | 27.3 cm |
| Packaging data | |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
| Other features | |
| Mounting type | Wall |
