Description
600dpi, CMOS CIS, RGB LED, 60ppm/120ipm, 80-sheets, USB 3.1, AC 100-240V, 285 x 180 x 178 mm
Productivity-boosting, elegantly designed desktop scanner
The compact imageFORMULA DR-M260 has a small frame, yet produces a big performance. This dependable scanner is packed with innovative features and delivers outstanding image quality, with capture speeds of up to 60 ppm/120 ipm.
Reasons To Buy
Slender, modern design
With its contemporary, compact body, the imageFORMULA DR-M260 integrates seamlessly into a wide variety of customer-facing environments.Fast scanning speeds
The new on-board processing chip takes the strain away from PCs, unlocking scanning speeds of up to 60 ppm in black and white, and 60 ppm in full colour.Virtuoso versatility
The DR-M260 tackles media from 27 g/m2 up to 413 g/m2, and furthers its flexible credentials by accepting credit cards, passports, and long-form documents.Description
Robust, reliable, high-speed document scanner, offering impressive image quality and fast capture speeds.Productivity-boosting, elegantly designed desktop scanner
The compact imageFORMULA DR-M260 has a small frame, yet produces a big performance. This dependable scanner is packed with innovative features and delivers outstanding image quality, with capture speeds of up to 60 ppm/120 ipm.
Specifications
| Scanning | |
|---|---|
| Output greyscale depth | 8 bit |
| Maximum scan size | 216 x 5588 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Output colour depth | 24 bit |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 60 ppm |
| ADF scan speed (colour, A4) | 60 ppm |
| Duplex ADF scan speed (b/w, A4) | 120 ipm |
| Duplex ADF scan speed (colour, A4) | 120 ipm |
| Sensor type | CMOS CIS |
| Light source | RGB LED |
| Scan file formats | |
| Daily duty cycle (max) | 7500 pages |
| Scan media weight | 27 - 413 g/m² |
| Design | |
| Built-in display | Yes |
| Scanner type | Sheet-fed scanner |
| Display | LCD |
| Product colour | Black |
| Performance | |
| Sensor type | CMOS CIS |
| Light source | RGB LED |
| Scan file formats | |
| Daily duty cycle (max) | 7500 pages |
| Scan drivers | ISIS, TWAIN |
| Input capacity | |
| Standard input capacity | 80 sheets |
| Paper handling | |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 5.59 m |
| Maximum ISO A-series paper size | A4 |
| Media thickness (min) | 0.04 mm |
| Scanning media types supported | Business Card, Plastic Card, Post Card(JPN) |
| Ports & interfaces | |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
| USB port | Yes |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| Software | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Scan drivers | ISIS, TWAIN |
| Power | |
| Power consumption (typical) | 23 W |
| Power consumption (standby) | 1.4 W |
| Power consumption (off) | 0.1 W |
| Input voltage | 100-240 V |
| Power supply type | AC |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width | 180 mm |
| Depth | 178 mm |
| Height | 285 mm |
| Weight | 3.6 kg |
| Packaging content | |
| Cables included | AC, USB |
| AC adapter included | Yes |
| Technical details | |
| Maximum scan width | 21.6 cm |
| Media thickness (min) | 0.04 mm |
| Scanner type | Sheet-fed scanner |
| Product colour | Black |
| Harmonized System (HS) code | 84716070 |
| Display | |
| Display | LCD |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Other features | |
| Scan media weight | 27 - 413 g/m² |
| Scanner type | Sheet-fed scanner |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
