Description
1 SIP, FXS, RJ-45, QoS, TLS, SRTP, 100-240VAC, 50-60Hz, 100 x 100 x 29.5 mm
The HT801 delivers powerful VoIP technology and routing capabilities to home and office environments, and allows users to successfully connect their analog devices to a manageable and powerful VoIP network. Built upon Grandstream’s market-leading SIP ATA/gateway technology, with millions of units successfully deployed worldwide, this powerful ATA features exceptional voice quality in various applications and environments. The HT801 comes with 1 easy-to-use FXS ports, state-of-the-art encryption with a unique security certificate per unit, automated provisioning for volume deployment and device management and outstanding network performance.
- Supports 1 SIP profile through a single FXS port and a single 10/100Mbps port
- TLS and SRTP security encryption technology to protect calls and accounts
- Automated provisioning options include TR-069 and XML config files
- Supports 3-way voice conferencing
- Failover SIP server automatically switches to secondary server if main server loses connection
- Supports T.38 Fax for creating Fax-over-IP
- Supports a wide range of caller ID formats
- Use with Grandstream’s UCM series of IP PBXs for Zero Configuration provisioning
- Supports advanced telephony features, including call transfer, call forward, call-waiting, do not disturb, message waiting indication, multilanguage prompts, flexible dial plan and more
Description
Designed for users looking to connect their analog devices to a VoIP network, in either a home or office. The HT801 is a powerful analog telephone adapter that is easily deployable and manageable. It comes equipped with 1 FXS ports to create a high-quality network solution.The HT801 delivers powerful VoIP technology and routing capabilities to home and office environments, and allows users to successfully connect their analog devices to a manageable and powerful VoIP network. Built upon Grandstream’s market-leading SIP ATA/gateway technology, with millions of units successfully deployed worldwide, this powerful ATA features exceptional voice quality in various applications and environments. The HT801 comes with 1 easy-to-use FXS ports, state-of-the-art encryption with a unique security certificate per unit, automated provisioning for volume deployment and device management and outstanding network performance.
- Supports 1 SIP profile through a single FXS port and a single 10/100Mbps port
- TLS and SRTP security encryption technology to protect calls and accounts
- Automated provisioning options include TR-069 and XML config files
- Supports 3-way voice conferencing
- Failover SIP server automatically switches to secondary server if main server loses connection
- Supports T.38 Fax for creating Fax-over-IP
- Supports a wide range of caller ID formats
- Use with Grandstream’s UCM series of IP PBXs for Zero Configuration provisioning
- Supports advanced telephony features, including call transfer, call forward, call-waiting, do not disturb, message waiting indication, multilanguage prompts, flexible dial plan and more
Specifications
| Design | |
|---|---|
| LED indicators | LAN, Power |
| Certification | FCC: 15 B CE: EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/NZS CISPR22, AS/NZS60950.1, S003 |
| Features | |
| Voice codecs | OPUS, G.711, G.723.1, G.726, G.729A, G.729B, iLBC |
| Protocols | |
| Supported network protocols | TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, TELNET, STUN, SIP (RFC3261), SIP TCP/TLS, SRTP, TR-069 |
| Network | |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Modulation | DTMF |
| Security | |
| Security algorithms | SRTP, SSL/TLS |
| Ports & interfaces | |
| Foreign eXchange Station (FXS) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Management features | |
| Web-based management | Yes |
| Syslog | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Power | |
| Output voltage | 5 V |
| Output current | 1 A |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Weight | 102 g |
| Dimensions (WxDxH) | 100 x 100 x 29.5 mm |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Voice codecs | OPUS, G.711, G.723.1, G.726, G.729A, G.729B, iLBC |
| Modulation | DTMF |
| Harmonized System (HS) code | 85176990 |
| Indication | |
| LED indicators | LAN, Power |
| Certificates | |
| Certification | FCC: 15 B CE: EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/NZS CISPR22, AS/NZS60950.1, S003 |
| Performance | |
| Certification | FCC: 15 B CE: EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/NZS CISPR22, AS/NZS60950.1, S003 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
