Description
IPQ-4018, 128MB RAM, 16MB Flash, Dual-band 2412-2484MHz / 5150MHz-5875MHz, 2 x 10/100/1000, PoE, 802.11ac, White
Even though the radio supports repeater mode, the two Ethernet ports give you the ability to extend your network with cables, even if PoE power is required, since the cAP ac supports 802.3af/at PoE input on the first port, and passive PoE output on the second port. Device supports IPsec hardware acceleration too.
The cAP ac is a feature packed device with a sleek enclosure, that can become inconspicuous with
the push of a button - the customizable mode button in the device center will turn off all lights and
sounds at it’s default configuration, but can be reconfigured to launch any RouterOS script.
Description
The cAP ac is a very capable and powerful wireless access point that looks beautiful on both walls and ceilings. The concurrent dual band wireless radio supports dual chain 2 GHz 802.11b/g/n and 5 GHz in a/n/ас standards, and will provide coverage in 360 degrees around it.Even though the radio supports repeater mode, the two Ethernet ports give you the ability to extend your network with cables, even if PoE power is required, since the cAP ac supports 802.3af/at PoE input on the first port, and passive PoE output on the second port. Device supports IPsec hardware acceleration too.
The cAP ac is a feature packed device with a sleek enclosure, that can become inconspicuous with
the push of a button - the customizable mode button in the device center will turn off all lights and
sounds at it’s default configuration, but can be reconfigured to launch any RouterOS script.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 867 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Frequency band | 2.412 - 2.484, 5.15 - 5.875 GHz |
| Receiver sensitivity | 2.4GHz: 1MBit/s: -100 @ 26dBm Tx 11MBit/s: -94 @ 26dBm Tx 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -78 @ 23dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -73 @ 22dBm Tx 5GHz: 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -80 @ 21dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -75 @ 20dBm Tx MCS9: -70 @ 18dBm Tx |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Certification | CE, FCC, IC, EAC, ROHS |
| Maximum data transfer rate | 867 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Processor model | IPQ4018 |
| Processor frequency | 716 MHz |
| Wireless LAN features | |
| Frequency band | 2.412 - 2.484, 5.15 - 5.875 GHz |
| Network | |
| Internal | No |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Memory | |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Frequency band | 2.412 - 2.484, 5.15 - 5.875 GHz |
| Receiver sensitivity | 2.4GHz: 1MBit/s: -100 @ 26dBm Tx 11MBit/s: -94 @ 26dBm Tx 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -78 @ 23dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -73 @ 22dBm Tx 5GHz: 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -80 @ 21dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -75 @ 20dBm Tx MCS9: -70 @ 18dBm Tx |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 867 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Processor model | IPQ4018 |
| Processor frequency | 716 MHz |
| Ports & interfaces | |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Power consumption (max) | 13 W |
| Output voltage | 57 V |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Active PoE, Passive PoE |
| DC voltage range | 17 - 57 V |
| Design | |
| Placement | Ceiling, Wall |
| Product colour | White |
| Internal | No |
| LED indicators | Yes |
| Certification | CE, FCC, IC, EAC, ROHS |
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 4 |
| Antenna gain level (max) | 2.5 dBi |
| Antenna features | Integrated antenna |
| Technical details | |
| Receiver sensitivity | 2.4GHz: 1MBit/s: -100 @ 26dBm Tx 11MBit/s: -94 @ 26dBm Tx 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -78 @ 23dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -73 @ 22dBm Tx 5GHz: 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -80 @ 21dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -75 @ 20dBm Tx MCS9: -70 @ 18dBm Tx |
| Harmonized System (HS) code | 85176990 |
| Processor | |
| Built-in processor | Yes |
| Certificates | |
| Certification | CE, FCC, IC, EAC, ROHS |
| Indication | |
| LED indicators | Yes |
| Weight & dimensions | |
| Width | 136 mm |
| Depth | 30 mm |
| Height | 136 mm |
| Packaging data | |
| Mounting kit | Yes |
| PoE adapter included | Yes |
| AC adapter included | Yes |
| Packaging content | |
| Mounting kit | Yes |
| PoE adapter included | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 50 °C |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
