Description
RB912R-2nD-LTm, none LTE (slot for miniPCI-e LTE card available), 4 W, 139 x 77 x 28,5 mm
The LtAP mini also has one 10/100 Ethernet LAN port for your wired devices. The RS232 serial port gives you console access for debugging. The unit has several powering options: 9-30 V PoE-in by Ethernet port, DC jack and microUSB.
LtAP mini has a special enclosure with with a wall mounting kit, two SIM slots to alternate between cellular providers, and integrated GPS support, making this a perfect device for use in moving vehicles like cars, buses or trains. Use the built in GPS module to track the location of your vehicle in real time, we have even provided a simple tracking application example in the RouterOS documentation, to help you start development of your platform. External GPS antenna is available for ordering separately (not included, product code GPSANT).
Description
The LtAP mini is a small waterproof wireless access point with integrated LTE antennas (with two u.fl pigtails) and miniPCI-e slot, so you can use your own LTE modem of your choice.The LtAP mini also has one 10/100 Ethernet LAN port for your wired devices. The RS232 serial port gives you console access for debugging. The unit has several powering options: 9-30 V PoE-in by Ethernet port, DC jack and microUSB.
LtAP mini has a special enclosure with with a wall mounting kit, two SIM slots to alternate between cellular providers, and integrated GPS support, making this a perfect device for use in moving vehicles like cars, buses or trains. Use the built in GPS module to track the location of your vehicle in real time, we have even provided a simple tracking application example in the RouterOS documentation, to help you start development of your platform. External GPS antenna is available for ordering separately (not included, product code GPSANT).
Specifications
| Data transmission | |
|---|---|
| Wi-Fi data rate (max) | 54 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 54 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | No |
| Wi-Fi data rate (max) | 54 Mbit/s |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 54 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 64 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Network | |
| Internal | No |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Memory | |
| Internal memory | 64 MB |
| Flash memory | 16 MB |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | No |
| Wi-Fi data rate (max) | 54 Mbit/s |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Maximum data transfer rate | 54 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 64 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Ports & interfaces | |
| RS-232 interface | Yes |
| WAN connection | Mobile network (SIM) |
| USB connector type | Micro-USB |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (max) | 4 W |
| AC input voltage | 8 - 30 V |
| Design | |
| Placement | Table |
| Product colour | Black |
| Internal | No |
| Antenna | |
| Antenna gain level (max) | 1.5 dBi |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Processor | |
| Built-in processor | Yes |
| Weight & dimensions | |
| Width | 139 mm |
| Depth | 77 mm |
| Height | 28.5 mm |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 70 °C |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
