Description
5 x Ethernet, PoE in, SFP ports, 6 W, 6 - 31 V, 212 g, MikroTik SwOS
Tested and recommended to use with MikroTik SFP modules: S-85DLC05D, S-31DLC20D and S-35/53LC20D (not included)
It is powered by an operating system designed specifically for MikroTik Switch products - SwOS.
SwOS is configurable from your web browser. It gives you all the basic functionality for a managed switch, plus more: Allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.
Description
The RB260GS is a small SOHO switch. It has five Gigabit Ethernet ports and one SFP cage powered by an Atheros Switch Chip.Tested and recommended to use with MikroTik SFP modules: S-85DLC05D, S-31DLC20D and S-35/53LC20D (not included)
It is powered by an operating system designed specifically for MikroTik Switch products - SwOS.
SwOS is configurable from your web browser. It gives you all the basic functionality for a managed switch, plus more: Allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.
Specifications
| Ports & interfaces | |
|---|---|
| SFP module slots quantity | 1 |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| Network | |
| 10G support | No |
| Design | |
| Product colour | White |
| LED indicators | Yes |
| Rack mounting | No |
| Power | |
| Power consumption (typical) | 6 W |
| Input voltage | 6 - 31 V |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) ports quantity | 1 |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -25 - 65 °C |
| Weight & dimensions | |
| Width | 113 mm |
| Depth | 139 mm |
| Height | 28 mm |
| Weight | 212 g |
| Technical details | |
| Product colour | White |
| Rack mounting | No |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Indication | |
| LED indicators | Yes |
| Other features | |
| Input voltage | 6 - 31 V |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
