Description
1x 10/100/1000 Mbit/s RJ-45, 716 MHz, PoE, 10-30 V, RouterOS
The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.
Key Features
- The SXTsq 5 ac is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides
- The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner
Description
The SXTsq 5 ac is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides.The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Performance | |
| 2.4 GHz | No |
| 5 GHz | Yes |
| Frequency band | 5.150 - 5.875 GHz |
| Receiver sensitivity | 6MBit/s 25 -96 54MBit/s 21 -80 MCS0 25 -96 MCS7 20 -75 MCS9 18 -70 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 256 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Processor frequency | 716 MHz |
| Wireless LAN features | |
| Frequency band | 5.150 - 5.875 GHz |
| Network | |
| Internal | No |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Memory | |
| Internal memory | 256 MB |
| Flash memory | 16 MB |
| Features | |
| 2.4 GHz | No |
| 5 GHz | Yes |
| Frequency band | 5.150 - 5.875 GHz |
| Receiver sensitivity | 6MBit/s 25 -96 54MBit/s 21 -80 MCS0 25 -96 MCS7 20 -75 MCS9 18 -70 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 256 MB |
| Flash memory | 16 MB |
| Built-in processor | Yes |
| Processor frequency | 716 MHz |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (max) | 7 W |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 10 - 30 V |
| Design | |
| International Protection (IP) code | IP55 |
| Placement | Pole, Wall |
| Product colour | White |
| Internal | No |
| Antenna | |
| Antenna type | Internal |
| Antenna gain level (max) | 16 dBi |
| Technical details | |
| Receiver sensitivity | 6MBit/s 25 -96 54MBit/s 21 -80 MCS0 25 -96 MCS7 20 -75 MCS9 18 -70 |
| Harmonized System (HS) code | 85176990 |
| Processor | |
| Built-in processor | Yes |
| Weight & dimensions | |
| Width | 129 mm |
| Depth | 129 mm |
| Weight | 295 g |
| Height | 34 mm |
| Package width | 255 mm |
| Package depth | 180 mm |
| Package height | 45 mm |
| Package weight | 492 g |
| Packaging data | |
| Package width | 255 mm |
| Package depth | 180 mm |
| Package height | 45 mm |
| Package weight | 492 g |
| Operational conditions | |
| Operating relative humidity (H-H) | -40 - 70% |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
