Description
Gigabit Ethernet PoE+ Media Converter, SFP SFP Open Slot, 802.3at, 30W, without SFP module
- PoE power supplier, PSE
- Sends data with high quality and additionally offers the highest level of failure safety
- A fast transfer in the gigabit range is guaranteed
- Upmarket SFP module with a range of up to 80 km
The media converters from DIGITUS® are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. With our comprehensive range of products, you can respond to your individual needs. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS® a reliable partner for your network technology.
Key Features
- PoE power supplier, PSE
- Compatible with the IEEE802.3af and IEEE802.3at standards
- PoE power supply via PIN 4/5(V-) and PIN 7/8(V+)
- Maximum total output of 30 watts
- Compatible with IEEE802.3, IEEE802.3u and IEEE802.3z standards
- Automatic cable recognition - Auto MDI/MDI-X function
- Auto recognition of full and half duplex
- Converts wire-based network signals into fiber optic signals
- Ports: 1x RJ45, 1x SFP
- Range of up to 80 km
- Diagnostic LEDs for status and activity monitoring
- Power supply: 48~52V DC
- Operating temperature: -20°C - 65°C
- Storage temperature: -40°C - 85°C
- Dimensions (mm): 95(L) x 71(W) x 26(H)
- MTBF: 500,000 hours
- Exclusive SFP Module
Description
The perfect converter solution for optical data transmission- PoE power supplier, PSE
- Sends data with high quality and additionally offers the highest level of failure safety
- A fast transfer in the gigabit range is guaranteed
- Upmarket SFP module with a range of up to 80 km
The media converters from DIGITUS® are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. With our comprehensive range of products, you can respond to your individual needs. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS® a reliable partner for your network technology.
Specifications
| Network | |
|---|---|
| Data transfer rate | 1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Converter input interface | 10Base-T, 100Base-T, 1000Base-T |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Auto MDI/MDI-X | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Fiber optic connector | SFP |
| Performance | |
| Maximum transfer distance | 80000 m |
| Mean time between failures (MTBF) | 500000 h |
| Features | |
| LED indicators | Activity, Link, Power |
| Product colour | Black |
| Internal | No |
| Ports & interfaces | |
| Power over Ethernet (PoE) ports quantity | 1 |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
| DC-in jack | Yes |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 30 W |
| Input voltage | 5 V |
| Output voltage | 48 - 52 V |
| External power adapter | Yes |
| Weight & dimensions | |
| Width | 71 mm |
| Depth | 95 mm |
| Height | 26 mm |
| Package volume | 1872 cm³ |
| Package depth | 240 mm |
| Package width | 130 mm |
| Package height | 60 mm |
| Package weight | 800 g |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 65 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Packaging data | |
| Package volume | 1872 cm³ |
| Package depth | 240 mm |
| Package width | 130 mm |
| Package height | 60 mm |
| Package weight | 800 g |
| Technical details | |
| Maximum transfer distance | 80000 m |
| Internal | No |
| Data transfer rate | 1000 Mbit/s |
| Harmonized System (HS) code | 85176990 |
| Indication | |
| LED indicators | Activity, Link, Power |
| Design | |
| Country of origin | China |
| LED indicators | Activity, Link, Power |
| Product colour | Black |
| Internal | No |
| Endurance | |
| Mean time between failures (MTBF) | 500000 h |
| Colour | |
| Product colour | Black |
| Logistics data | |
| Country of origin | China |
| Master (outer) case width | 410 mm |
| Master (outer) case length | 570 mm |
| Master (outer) case height | 280 mm |
| Master (outer) case gross weight | 8 kg |
| Master (outer) case volume | 65436 cm³ |
| Products per master (outer) case | 110 pc(s) |
| Harmonized System (HS) code | 85176990 |
| UK Trade Tariff code | 85176200 |
