Datalogic Magellan 1500i Barcode module bar barcode readers 1D/2D Black

Magellan 1500i, Std Configuration, 2D, Tilting Stand, USB A Cable

Description

The Magellan 1500i is a high performance presentation scanner from Datalogic for a
variety of applications including retail POS, pharmacy and customer service. It provides outstanding performance on 1D and 2D barcodes from a variety of printed and mobile sources. The addition of Digimarc® Barcodes watermark decoding makes this a uniquely capable scanner.

Specifications

Scanning
Type	Barcode module bar barcode readers
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86100 lx
Optical sensor resolution (W x H)	1280 x 800 pixels
Ports & interfaces
Connectivity technology	Wired
Standard interfaces	RS-232, USB
Performance
International Protection (IP) code	IP52
Product colour	Black
Light levels (direct sunlight)	0 - 86100 lx
Design
Type	Barcode module bar barcode readers
International Protection (IP) code	IP52
Product colour	Black
Power
Input voltage	5 V
Weight & dimensions
Width	60 mm
Depth	75 mm
Height	106 mm
Weight	240 g
Technical details
Type	Barcode module bar barcode readers
International Protection (IP) code	IP52
Product colour	Black
Harmonized System (HS) code	84716070
Compliance certificates	RoHS
Packaging data
Cables included	USB
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Light levels (direct sunlight)	0 - 86100 lx
Packaging content
Cables included	USB
Logistics data
Harmonized System (HS) code	84716070
