Back-UPS Pro, 1600VA/960W, Tower, 230V, 8x IEC C13 outlets, Sine Wave, AVR, USB Type A + C ports, LCD, User Replaceable Battery
Description
This APC Back-UPS Pro offers premium power protection for high performance computer systems, routers/modems, external storage devices, game consoles and other electronics in your home or business. The 1600VA tower UPS has 8 total outlets, 6 of which are battery back up and surge protection, and 2 that are surge protection only. It has a surge energy rating of 509 Joules. It has 2 USB ports (Type A + C) for smart charging of personal devices. Its runtime at 100 Watts is 1 hour 18 minutes. Its dimensions are 26 x 10 x 36.8 cm and 12.1 kg. The Back-UPS Pro family offers guaranteed power protection for high-performance computer systems, routers, external storage devices, game consoles, and other home and business electronics. This UPS has a 2-year warranty and CE product certification. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
Specifications
| Power |
|---|
| Output power |
960 W |
| Input operation voltage (min) |
176 V |
| Input operation voltage (max) |
294 V |
| Output operation voltage (max) |
230 V |
| Surge energy rating |
509 J |
| Maximum current |
10 A |
| Output power capacity |
1.6 kVA |
| Performance |
|---|
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Power protection features |
Overload |
| Noise level |
45 dB |
| Audible alarm(s) |
Yes |
| Features |
|---|
| Output frequency |
50/60 Hz |
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output power |
960 W |
| Input operation voltage (min) |
176 V |
| Input operation voltage (max) |
294 V |
| Output operation voltage (max) |
230 V |
| Surge energy rating |
509 J |
| Maximum current |
10 A |
| Power protection features |
Overload |
| Noise level |
45 dB |
| Audible alarm(s) |
Yes |
| Output power capacity |
1.6 kVA |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
|---|
| USB port |
Yes |
| AC outlets quantity |
8 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C14 coupler |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Battery |
|---|
| Battery life (max) |
5 year(s) |
| Number of batteries supported |
1 |
| Battery capacity |
260 Ah |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
16 h |
| Hot-swap battery |
Yes |
| Cold start |
Yes |
| Automatic battery test |
Yes |
| Design |
|---|
| Form factor |
Mini Tower |
| Product colour |
Black |
| Certification |
A-tick, C-tick, CE, EAC, GS Mark, RCM, TISI, REACH |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 15000 m |
| Technical details |
|---|
| Output frequency |
50/60 Hz |
| Sustainability certificates |
Green Premium |
| Harmonized System (HS) code |
85078000 |
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Package width |
223 mm |
| Package depth |
482 mm |
| Package height |
359 mm |
| Weight |
12.1 kg |
| Width |
100 mm |
| Package weight |
13.8 kg |
| Height |
260 mm |
| Depth |
368 mm |
| Packaging data |
|---|
| Package width |
223 mm |
| Package depth |
482 mm |
| Package height |
359 mm |
| Package weight |
13.8 kg |
| Logistics data |
|---|
| Harmonized System (HS) code |
85078000 |
| Certificates |
|---|
| Certification |
A-tick, C-tick, CE, EAC, GS Mark, RCM, TISI, REACH |
