5GHz, 2X2 MU-MIMO, Gigabit Ethernet, IP67 / IP68, EU Cord
Key Features
- MicroPOP Applications: ePMP 3000L is ideally suited for areas with low density or small numbers of subscribers. With support for narrow-band sectors and omnis, coverage can be added exactly where needed
- Frequency Reuse: Supports GPS synchronization and SM Transmit power control to allow for frequency re-use
- Unmatched Performance and Scalability: With the efficient Cambium Networks MAC protocol and advanced air-fairness scheduler the ePMP 3000L supports high performance and low consistent latency to subscribers
Description
Cambium Networks’ ePMP™ product line has set the standard for high performance, scalability and reliability in harsh interference environments all at a compelling price. The ePMP 3000L is the third generation access point (AP) that carries on the interference tolerance mechanisms with an emphasis on high-performance in low-density point to multipoint sectors.
Specifications
| Data transmission |
|---|
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Performance |
|---|
| 2.4 GHz |
No |
| 5 GHz |
Yes |
| IGMP snooping |
Yes |
| Frequency band |
4.91 - 5.97 GHz |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Modulation |
256-QAM, OFDM |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Certification |
EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
Z8H-89FT0047
109W-0047 |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Wireless LAN features |
|---|
| Frequency band |
4.91 - 5.97 GHz |
| Modulation |
256-QAM, OFDM |
| Network |
|---|
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Management features |
|---|
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Features |
|---|
| 2.4 GHz |
No |
| 5 GHz |
Yes |
| Frequency band |
4.91 - 5.97 GHz |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Modulation |
256-QAM, OFDM |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Security |
|---|
| IGMP snooping |
Yes |
| Security algorithms |
128-bit AES, SSH |
| Protocols |
|---|
| Management protocols |
HTTPS, SNMPv2c, SSH |
| Supported protocols |
IPv4/IPV6 , UDP, TCP, IP, ICMP, SNMPv2c, HTTPS, STP
EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
109W-0047
Z8H-89FT0047 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Cabling technology |
10/100/1000Base-T(X) |
| Power |
|---|
| Power consumption (max) |
15 W |
| Power consumption (typical) |
12 W |
| Power over Ethernet (PoE) |
Yes |
| AC input voltage |
30 V |
| Design |
|---|
| International Protection (IP) code |
IP68 |
| Placement |
Wall |
| Product colour |
White |
| Certification |
EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
Z8H-89FT0047
109W-0047 |
| Antenna |
|---|
| Number of connectors |
3 |
| Antenna type |
External |
| Antenna connector type |
RP-SMA |
| Antenna features |
Detachable antenna |
| Technical details |
|---|
| Harmonized System (HS) code |
85176990 |
| Certificates |
|---|
| Certification |
EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
Z8H-89FT0047
109W-0047 |
| Weight & dimensions |
|---|
| Width |
84 mm |
| Depth |
32 mm |
| Weight |
500 g |
| Height |
223 mm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 60 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
