UniFi FlexHD, 1 x 10/100/1000 Ethernet Port, 2.4/5 GHz, 300/1733 Mbps, 802.11 a/b/g/n/ac/ac-wave2, WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Key Features
- 802.11ac Wave 2 Technology
- 5 GHz Radio: 802.11ac Wave 2, 4x4 MU-MIMO with Radio Rate of 1.733 Gbps
- 2.4 GHz Radio 802.11n: 2x2 MIMO with Radio Rate of 300 Mbps
- Indoor and Outdoor Use
- Tabletop, Wall, and Pole Mounting Brackets Included
- Seamless Integration and Management with UniFi Network Solution
Description
Small and sleek, yet powerful, the 802.11ac 4x4 AP is ideal for enterprises, businesses, and homes. The modern yet discreet design allows placement near users for optimal performance.
Specifications
| Data transmission |
|---|
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Maximum data transfer rate |
1733 Mbit/s |
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Reset button |
Yes |
| Frequency band |
2.4/5 GHz |
| VLAN support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Certification |
CE, FCC, IC |
| Maximum data transfer rate |
1733 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Wireless LAN features |
|---|
| Frequency band |
2.4/5 GHz |
| Network |
|---|
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Management features |
|---|
| VLAN support |
Yes |
| Certificates |
|---|
| Certification |
CE, FCC, IC |
| Features |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Frequency band |
2.4/5 GHz |
| VLAN support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Maximum data transfer rate |
1733 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
| Maximum data transfer rate (5 GHz) |
1733 Mbit/s |
| Virtual LAN features |
Tagged VLAN |
| Security |
|---|
| Security algorithms |
AES, TKIP, WEP, WPA-Enterprise, WPA-PSK, WPA2 |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power consumption (max) |
10.5 W |
| Power over Ethernet (PoE) |
Yes |
| Input current |
0.32 A |
| AC input voltage |
44 - 57 V |
| Design |
|---|
| Placement |
Ceiling, Pole, Table, Wall |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Status, System |
| Certification |
CE, FCC, IC |
| Antenna |
|---|
| Antenna type |
Internal |
| Technical details |
|---|
| Reset button |
Yes |
| Harmonized System (HS) code |
85176990 |
| Indication |
|---|
| LED indicators |
Status, System |
| Weight & dimensions |
|---|
| Depth |
159.5 mm |
| Weight |
315 g |
| Height |
48.5 mm |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-30 - 70 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
