DELL 2X15K network transceiver module Fiber optic 100000 Mbit/s QSFP28 850 nm

100GbE QSFP28, SR4, MPO12, MMF

Description

The Dell™ QSFP28 transceiver delivers fiber connectivity to extend the range of your network. This hot-pluggable transceiver with QSFP28 (Quad Form Factor Pluggable) footprint features a MPO-12 connector. The Dell networking 100GbE-SR4 QSFP28 transceiver provides 100GbE connectivity up to 100m .

Additionally, it provides a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power, and transceiver supply voltage.

Specifications

Performance
SFP transceiver type	Fiber optic
Fiber optic connector	MPO12
Maximum transfer distance	100 m
Wavelength	850 nm
Maximum data transfer rate	100000 Mbit/s
Interface type	QSFP28
Multi-mode fiber (MMF) supported	Yes
Ethernet interface type	100 Gigabit Ethernet
SFP transceiver standard	SR4
Compatible products	- Networking S5232F-ON - Networking S5296F-ON - Networking S5248F-ON - Networking S5212F-ON - Networking S5224F-ON
Brand compatibility	Dell
Harmonized System (HS) code	85369010
Features
Compatible products	- Networking S5232F-ON - Networking S5296F-ON - Networking S5248F-ON - Networking S5212F-ON - Networking S5224F-ON
Brand compatibility	Dell
Network
SFP transceiver type	Fiber optic
Fiber optic connector	MPO12
Maximum data transfer rate	100000 Mbit/s
Interface type	QSFP28
Ethernet interface type	100 Gigabit Ethernet
Packaging content
Quantity per pack	1 pc(s)
Technical details
Maximum transfer distance	100 m
Wavelength	850 nm
Compatible products	- Networking S5232F-ON - Networking S5296F-ON - Networking S5248F-ON - Networking S5212F-ON - Networking S5224F-ON
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85369010
