Epson WorkForce DS-32000 Sheet-fed scanner 600 x 600 DPI A3 Black, White

90ppm, 180ipm, 40000 daily duty cycles, 300 dpi, AC 100 V - 240 V, 5.8 kg

Key Features

• High-volume scanning: 90ppm/180ipm & 40,000 daily duty cycles
• Adjustable chassis design: Normal, Horizontal and Compact options to suit your space
• Media versatility: Scan passports and bound media up to 6mm in thickness
• Control and security: Advanced paper handing with paper-protection sensors
• A4 and A3 flatbed options: Scan books and bound media with optional flatbed scanners

Description

Transform your scanning environment with the DS-32000 – a high-performance 90ppm scanner that adjusts to your requirements. Using advanced technology and with versatile media handling, you can confidently scan up to 40,000 pages a day.

Thanks to Epson's new Complex Production Architecture, the DS-32000 has been engineered to the highest standards to meet the demands of busy office environments.

High in capacity and with a robust design, the Automatic Document Feeder (ADF) has the ability to scan the widest range of media in its class¹. Scan passports, passbooks, ID cards and large-format documents.

The DS-32000 features a unique adjustable chassis design - Normal, Horizontal and Compact - allowing customers to choose the best physical position for their scanning needs. When in the compact position, the unit folds for easy storage.

Put users in control with a 2.7" backlit touchscreen that can display pre-defined scan jobs and highlights machine cleaning and maintenance requirements with easy-to-follow, step-by-step instructions.

The inbuilt advanced paper-protection sensors also prevent documents from being damaged and ultra-sonic sensors ensure all documents are scanned, maintaining data integrity.

The DS-32000 comes with Document Capture Pro 3.0 software with inbuilt OCR functionality supporting crisp, clear images. A wide range of drivers, including TWAIN, ISIS, WIA, SANE, and ICA, allow for easy integration into most document management systems.

For added flexibility and convenience, the optional A4 (DS-5500) and A3 (DS-50000) flatbed scanners enable scanning of books, bound, and other media.

Specifications

Scanning
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	10 bit
Output colour depth	8 bit
ADF scan speed (b/w, A4)	90 ppm
Sensor type	CIS
Daily duty cycle (max)	40000 pages
Design
Built-in display	Yes
Scanner type	Sheet-fed scanner
Display diagonal	6.86 cm (2.7")
Display	LCD
Product colour	Black, White
Performance
Sensor type	CIS
Daily duty cycle (max)	40000 pages
Input capacity
Auto document feeder (ADF) input capacity	120 sheets
Paper handling
Maximum ISO A-series paper size	A3
Ports & interfaces
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)
USB port	Yes
USB version	3.2 Gen 1 (3.1 Gen 1)
Power
Power consumption (typical)	20 W
Power consumption (standby)	11 W
Power consumption (off)	0.1 W
Input voltage	100 - 240 V
Power supply type	AC
Sleep mode	Yes
Weight & dimensions
Width	371 mm
Depth	208 mm
Height	219 mm
Weight	5.8 kg
Packaging content
AC adapter included	Yes
Manual	Yes
Display
Display diagonal	6.86 cm (2.7")
Display	LCD
Technical details
Scanner type	Sheet-fed scanner
Product colour	Black, White
Harmonized System (HS) code	84716070
Operational conditions
Operating relative humidity (H-H)	15 - 80%
Storage relative humidity (H-H)	15 - 85%
Other features
Scanner type	Sheet-fed scanner
Logistics data
Harmonized System (HS) code	84716070
