netPower 15FR, 16 x 10/100 Ethernet ports, 2 x SFP ports, 304 x 212 x 71 mm
Description
With netPower 15FR switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept - aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.
You don’t have to worry about power options in the attic or the utility room – netPower 15FR has 15 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Another Ethernet port has PoE-out – you can use it to power an aggregate link such as our Wireless Wire Dish or a security camera, for example.
There are two SFP ports for fiber connectivity. The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower 15FR – bringing the cost down and the speed up!
netPower 15FR has a non-blocking throughput of 3.6 Gbps, switching capacity of 7.2 Gbps and forwarding rate of 5.4 Mpps.
Specifications
| Power |
|---|
| Power connector |
DC-in jack |
| Power consumption (max) |
29 W |
| DC input voltage |
18 - 57 V |
| Technical details |
|---|
| Product colour |
White |
| Processor frequency |
800 MHz |
| Built-in processor |
Yes |
| Ports & interfaces |
|---|
| SFP module slots quantity |
2 |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Power connector |
DC-in jack |
| Network |
|---|
| Ethernet LAN data rates |
10,100 Mbit/s |
| Data transmission |
|---|
| Throughput |
3600 Mpps |
| Switching capacity |
7.2 Gbit/s |
| Forwarding rate |
5.4 Mpps |
| Certificates |
|---|
| Certification |
CE/RED, EAC, ROHS |
| Memory |
|---|
| Memory type |
RAM |
| Internal memory |
256 MB |
| Flash memory |
16 MB |
| Design |
|---|
| Product colour |
White |
| Certification |
CE/RED, EAC, ROHS |
| Performance |
|---|
| Processor frequency |
800 MHz |
| Memory type |
RAM |
| Internal memory |
256 MB |
| Flash memory |
16 MB |
| Built-in processor |
Yes |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 70 °C |
| Weight & dimensions |
|---|
| Width |
304 mm |
| Depth |
212 mm |
| Height |
71 mm |
| Other features |
|---|
| Ethernet LAN data rates |
10,100 Mbit/s |
