Indoor fixed 6 MP mini dome with 360° panoramic view, White
Key Features
- 360° panoramic overview; Environmentally friendly materials; Forensic WDR, Lightfinder, day/night functionality; Small and discreet design; Zipstream supporting H.264 and H.265
Description
AXIS M3067-P can deliver 360° panoramic overviews as well as a variety of dewarped views. It supports day/night functionality for improved sensitivity in poor light. And, Axis Lightfinder and Forensic WDR for true colors and great details in challenging light. Furthermore, it features Axis Zipstream with H.264/H.265 and a powerful capacity for analytics. AXIS M3067-P is delivered factory focused and features digital roll functionality for easy installation. Made from environmentally-friendly materials, it’s re-paintable to blend in with any surroundings and there’s black, vandal-resistant and smoke-detector casings available as accessories
Specifications
| Performance |
|---|
| Type |
IP security camera |
| Connectivity technology |
Wired |
| Placement supported |
Indoor |
| Design |
|---|
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Camera |
|---|
| Minimum illumination |
0.04 lx |
| Angle of rotation |
360° |
| Camera shutter speed |
1/16000 - 1 s |
| Camera pan control |
Yes |
| Camera tilt control |
Yes |
| Lens viewing angle, horizontal |
185° |
| Lens viewing angle, vertical |
185° |
| Progressive scan |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors |
1 |
| Lens system |
|---|
| Number of lenses |
1 |
| Fixed focus |
Yes |
| Minimum aperture number |
2 |
| Fixed focal length |
1.6 mm |
| Night vision |
|---|
| Night vision |
Yes |
| LED type |
IR |
| Video |
|---|
| Image quality adjustment |
Brightness, Contrast, Mirror, Saturation, Sharpness |
| Video compression formats |
H.264, H.265 |
| Maximum resolution |
2560 x 1920 pixels |
| Supported graphics resolutions |
2560 x 1440, 2560 x 1920 |
| Frame rate |
60 fps |
| Video streaming |
Yes |
| Total megapixels |
6 MP |
| Video intelligence analytic |
Yes |
| Network |
|---|
| Bluetooth |
No |
| Ethernet interface type |
Fast Ethernet |
| Quality of Service (QoS) support |
Yes |
| Streaming method |
Multicast |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
SD |
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Security |
|---|
| Alert notification type |
E-mail |
| Motion sensor |
Yes |
| Security algorithms |
HTTPS, SSL/TLS, SNMP, SNMPv2, SSH |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Password protection |
Yes |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
6.49 W |
| Power consumption (typical) |
3.7 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
5 - 95% |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Weight & dimensions |
|---|
| Height |
49 mm |
| Diameter |
10.1 cm |
| Weight |
300 g |
| Packaging content |
|---|
| Number of cameras |
1 |
| Manual |
Yes |
| Bundled software |
Windows® decoder 1-user license |
| Other features |
|---|
| Video compression formats |
H.264, H.265 |
| Logistics data |
|---|
| Harmonized System (HS) code |
85258900 |
