Description
150m Cat.6 TosLink (Optical) and Coaxial Digital Audio Extender
Supporting both stereo and multi-channel audio extension, this extender will allow for impressive three-dimensional surround sound performance to compliment films and games when connected to the audio source device, as well as crystal clear speech from user generated audio. This provides the user with an excellent point to point solution, ideal for use in immersive residential cinema rooms or creating a more attractive and enticing retail experience.
PoC (Power over Cable) functionality, the supply of power and data signals over Cat.6 cable on a point to point connection between the transmitter and receiver also brings additional flexibility as only one power supply is required at the transmitter unit, ideal when power outlets are limited at the receiver end of the installation.
Please note: simultaneous output is only possible when identical 96KHz sample rates are used
Key Features
- Extends TosLink (Optical) and coaxial digital audio up to 150m over network cable
- Supports stereo and multi-channel audio formats including Dolby Digital and DTS
- Supports PoC (Power over Cat Cable) from the transmitter to receiver
- Simultaneous audio output
- 2 year warranty
Description
The Lindy 150m Cat.6 TosLink (Optical) and Coaxial Digital Audio Extender is a high-quality solution for extending digital audio signals over long distances, using standard network cable. With TosLink (Optical) and coaxial inputs and outputs, this extender can be easily used with a variety of AV source devices including TVs and amplifiers, with speakers or soundbars located at the receiver side.Connected audio can be output simultaneously to provide splitting functionality from a single input, great for smaller audio broadcasting setups in underground railway stations, bus depots or medical facilities. This also allows simple conversion of TosLink and Coaxial signals into their opposing output.Supporting both stereo and multi-channel audio extension, this extender will allow for impressive three-dimensional surround sound performance to compliment films and games when connected to the audio source device, as well as crystal clear speech from user generated audio. This provides the user with an excellent point to point solution, ideal for use in immersive residential cinema rooms or creating a more attractive and enticing retail experience.
PoC (Power over Cable) functionality, the supply of power and data signals over Cat.6 cable on a point to point connection between the transmitter and receiver also brings additional flexibility as only one power supply is required at the transmitter unit, ideal when power outlets are limited at the receiver end of the installation.
Please note: simultaneous output is only possible when identical 96KHz sample rates are used
Specifications
| Features | |
|---|---|
| Material | Metal |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
| Audio formats supported | DTS, LPCM |
| Type | AV transmitter & receiver |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 150 m |
| Product colour | Black |
| Chipset | EL5171/ EL5172 |
| Technical details | |
| Material | Metal |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
| Package type | Box |
| Audio formats supported | DTS, LPCM |
| Type | AV transmitter & receiver |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 150 m |
| Product colour | Black |
| Connectivity technology | Wired |
| Compliance certificates | RoHS |
| Ports & interfaces | |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Digital audio coaxial in | 1 |
| Digital audio optical input type | TOSLINK |
| Digital audio optical in | 1 |
| Digital audio coaxial out | 1 |
| Digital audio optical out | 1 |
| Power | |
| Operating voltage (transmitter) | 12 V |
| Current | 1.25 A |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Weight & dimensions | |
| Receiver weight | 168 g |
| Transmitter weight | 168 g |
| Transmitter dimensions (WxDxH) | 65.9 x 26.9 x 53.1 mm |
| Receiver dimensions (WxDxH) | 65.9 x 26.9 x 53.1 mm |
| Package depth | 60 mm |
| Package width | 190 mm |
| Package height | 145 mm |
| Package weight | 405 g |
| Packaging data | |
| Package type | Box |
| Package depth | 60 mm |
| Package width | 190 mm |
| Package height | 145 mm |
| Package weight | 405 g |
| Packaging content | |
| AC adapter included | Yes |
| Manual | Yes |
| Included power plug types | EU, UK, US |
