58.4cm (23") Full HD 1920 x 1080 W-LED IPS, 16:9, 250cd/m², 16.78M, 6ms, 178°/178°, 1000:1
Key Features
- 58.4cm (23") Full HD 1920 x 1080 W-LED IPS
- 6ms, 16:9, 250cd/m², 1000:1
- USB, VGA, HDMI, DisplayPort
Description
Enhance your work and experience brilliant visuals on the ThinkVision T23i-20. View crystal-clear details from all angles on this 23-inch monitor that has an In-Plane Switching panel and anti-glare display. Its ultra-thin, 3-side NearEdgeless bezels offer wide screen real estate to let you create and collaborate efficiently. Multiple ports on the ThinkVision T23i-20 allow you to connect to peripherals effortlessly. While enabling efficient working, the monitor, with ergonomic stand and TÜV Rheinland Eye Comfort certification, ensures that you work comfortably.
Specifications
| Audio |
|---|
| Built-in speaker(s) |
No |
| Performance |
|---|
| Built-in speaker(s) |
No |
| Built-in camera |
No |
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.78 million colours |
| Native aspect ratio |
16:9 |
| Pixel density |
95.78 ppi |
| Maximum refresh rate |
60 Hz |
| HD type |
Full HD |
| Display technology |
LED |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2652 x 0.2652 mm |
| Aspect ratio |
16:9 |
| Viewable size, horizontal |
50.9 cm |
| Viewable size, vertical |
28.6 cm |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Supported video modes |
1080p |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
6 ms |
| Display diagonal |
58.4 cm (23") |
| Contrast ratio (typical) |
1000:1 |
| Response time (fast) |
4 ms |
| NTSC coverage (typical) |
75% |
| Touchscreen |
No |
| Panel type |
IPS |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
8 |
| Multimedia |
|---|
| Built-in speaker(s) |
No |
| Built-in camera |
No |
| Design |
|---|
| Feet colour |
Black |
| Certification |
CCC, TCO, TCO Edge, TÜV |
| Product colour |
Black |
| Front bezel colour |
Black |
| Colour name |
Raven Black |
| Camera |
|---|
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-B |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
4 |
| DVI port |
No |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Audio input |
No |
| Audio output |
Yes |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| Technical details |
|---|
| Height (without stand) |
316.3 mm |
| Depth (without stand) |
44.8 mm |
| Width (without stand) |
521.8 mm |
| Feet colour |
Black |
| Cable lock slot |
Yes |
| HDMI |
Yes |
| Product colour |
Black |
| Front bezel colour |
Black |
| Sustainability certificates |
EPEAT Silver, ENERGY STAR |
| Compliance certificates |
RoHS |
| Weight (with stand) |
5.59 kg |
| Touchscreen |
No |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 35° |
| Pivot |
Yes |
| On Screen Display (OSD) |
Yes |
| Pivot angle |
-90 - 90° |
| Number of OSD languages |
8 |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
47/63 Hz |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
14.5 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
C |
| Energy consumption (SDR) per 1000 hours |
11 kWh |
| European Product Registry for Energy Labelling (EPREL) code |
297941 |
| Weight & dimensions |
|---|
| Height (without stand) |
316.3 mm |
| Depth (without stand) |
44.8 mm |
| Width (without stand) |
521.8 mm |
| Width (with stand) |
521.8 mm |
| Depth (with stand) |
200 mm |
| Height (with stand) |
554.3 mm |
| Weight (with stand) |
5.59 kg |
| Weight (without stand) |
3.32 kg |
| Package width |
599 mm |
| Package depth |
175 mm |
| Package height |
387 mm |
| Package weight |
7.5 kg |
| Packaging data |
|---|
| Package width |
599 mm |
| Package depth |
175 mm |
| Package height |
387 mm |
| Package weight |
7.5 kg |
| Stand included |
Yes |
| Packaging content |
|---|
| Stand included |
Yes |
| Sustainability |
|---|
| European Product Registry for Energy Labelling (EPREL) code |
297941 |
| Sustainability certificates |
EPEAT Silver, ENERGY STAR |
| Other features |
|---|
| Certification |
CCC, TCO, TCO Edge, TÜV |
| Compliance certificates |
RoHS |
| Height (without stand) |
316.3 mm |
| Depth (without stand) |
44.8 mm |
| Width (without stand) |
521.8 mm |
| HDMI |
Yes |
| Energy efficiency scale |
A to G |
| Touchscreen |
No |
| Front bezel colour |
Black |
| Certificates |
|---|
| Certification |
CCC, TCO, TCO Edge, TÜV |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
