Description
Wi-Fi, USB 2.0, 2.4 GHz, 1T1R, 7.1x14.9x17.5 mm
Wireless 802.11n Standard | Up to 150Mbps
EW-7811Un V2 complies with wireless IEEE802.11b/g/n standards. Built with the latest wireless technology, the EW-7811Un V2 can increase your wireless coverage up to 3 times as much and greatly help reduce “dead spots” compared to your old 11g adapter. Transmission data rate can go up to 150Mbps when connected to a 802.11n device. It also extends its wireless signal distance, and provides more reliable wireless connections than standard IEEE 802.11g wireless networks.
Green WLAN | Improved Energy Efficiency
The EW-7811Un V2 has adapted a clever protocol. This wireless USB adapter smartly adjusts its power output according to the transmission distance and CPU offload. It drastically reduces power consumption when the connection is in idle. Designed with green WLAN technology, the EW-7811Un V2 power consumption can be reduced with an average of 20% to 50%.
Supports WPS | Wi-Fi Protected Setup
Wi-Fi Protected Setup (WPS) is a standard for easy and secure establishment of wireless networks. This wireless USB adapter supports software WPS-compatible configuration. With a few clicks, your wireless network and router are immediately secured.
Supports Multi-Language Easy Setup Wizard
The included 16 languages easy setup wizard and friendly UI will walk you through configuring EW-7811Un V2 to your wireless network.
Tiny and Stylish | Design for Laptops
Can be easily plugged into any laptop without sacrificing portability and looks. Furthermore, it is designed with details in mind, such as not blocking other ports or be in the way of other USB devices/cables.
Embedded Wireless Adapter Solution for Industrial IoT (IIoT)
Looking to add wireless connectivity to your product, device, or machine? Embedded with Edimax wireless USB adapters, supports various Wi-Fi and Bluetooth standards, delivers a completely connected, always-on experience for your customers. With more than 30 years of manufacturing integration experience, trust our proven expertise and first-class support to power your IoT application.
Key Features
- N150: Complies with wireless 802.11b/g/n standards with data rate up to 150Mbps (2.4GHz)
- Small, Stylish Design: World’s smallest N150 Wi-Fi Adapter
- Secure Wi-Fi: Features 64/128-bit WEP, WPA, WPA2 encryption for high level of security
- One-Click Wireless Connections: Features a software WPS (Wi-Fi Protected Setup) button for easy wireless connections
- Supports 802.11e WMM wireless QoS Feature
- Supports power saving mechanism
- Supports Windows, MAC OS and Linux
Description
EW-7811Un V2 is a nano USB wireless adapter that supports maximum range and speed. Despite the size, this tiny USB adapter supports higher data rate of up to 150Mbps when connecting with wireless 802.11n device which is 3 times faster than your normally 11g connection. You can just plug it into computer's USB port and enjoy incredible high-speed wireless network access. This is for sure the trendiest piece of upgrade you can make to your wireless network.Wireless 802.11n Standard | Up to 150Mbps
EW-7811Un V2 complies with wireless IEEE802.11b/g/n standards. Built with the latest wireless technology, the EW-7811Un V2 can increase your wireless coverage up to 3 times as much and greatly help reduce “dead spots” compared to your old 11g adapter. Transmission data rate can go up to 150Mbps when connected to a 802.11n device. It also extends its wireless signal distance, and provides more reliable wireless connections than standard IEEE 802.11g wireless networks.
Green WLAN | Improved Energy Efficiency
The EW-7811Un V2 has adapted a clever protocol. This wireless USB adapter smartly adjusts its power output according to the transmission distance and CPU offload. It drastically reduces power consumption when the connection is in idle. Designed with green WLAN technology, the EW-7811Un V2 power consumption can be reduced with an average of 20% to 50%.
Supports WPS | Wi-Fi Protected Setup
Wi-Fi Protected Setup (WPS) is a standard for easy and secure establishment of wireless networks. This wireless USB adapter supports software WPS-compatible configuration. With a few clicks, your wireless network and router are immediately secured.
Supports Multi-Language Easy Setup Wizard
The included 16 languages easy setup wizard and friendly UI will walk you through configuring EW-7811Un V2 to your wireless network.
Tiny and Stylish | Design for Laptops
Can be easily plugged into any laptop without sacrificing portability and looks. Furthermore, it is designed with details in mind, such as not blocking other ports or be in the way of other USB devices/cables.
Embedded Wireless Adapter Solution for Industrial IoT (IIoT)
Looking to add wireless connectivity to your product, device, or machine? Embedded with Edimax wireless USB adapters, supports various Wi-Fi and Bluetooth standards, delivers a completely connected, always-on experience for your customers. With more than 30 years of manufacturing integration experience, trust our proven expertise and first-class support to power your IoT application.
Specifications
| Ports & interfaces | |
|---|---|
| Internal | No |
| Interface | WLAN |
| Host interface | USB |
| Connectivity technology | Wireless |
| Bandwidth | |
| Maximum data transfer rate | 150 Mbit/s |
| Wireless LAN features | |
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi | Yes |
| WLAN data transfer rates supported | 1,2,5.5,6,9,11,12,24,36,48,54,72,150 Mbit/s |
| Antenna | |
| Frequency range | 2.4 - 2.4835 GHz |
| Technical details | |
| Product colour | Black |
| Harmonized System (HS) code | 85176990 |
| Compliance certificates | RoHS |
| Network | |
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2 |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| WLAN data transfer rates supported | 1,2,5.5,6,9,11,12,24,36,48,54,72,150 Mbit/s |
| Frequency range | 2.4 - 2.4835 GHz |
| Maximum data transfer rate | 150 Mbit/s |
| Design | |
| Product colour | Black |
| Certification | CE (DoC), FCC |
| Internal | No |
| LED indicators | Activity, Link |
| Component for | PC |
| Software | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Linux operating systems supported | Yes |
| Power | |
| USB powered | Yes |
| Indication | |
| LED indicators | Activity, Link |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Linux operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 14.9 mm |
| Depth | 17.5 mm |
| Height | 7.1 mm |
| Weight | 2 g |
| Security | |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2 |
| Performance | |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Linux operating systems supported | Yes |
| Certificates | |
| Certification | CE (DoC), FCC |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Harmonized System (HS) code | 85176990 |
