Description
KDC280C-BLE 2D Imager Bluetooth Low Energy Barcode Scanner & Data Collector
A built-in display and keypad eliminate blind erroneous data collection and enable interactive processes.
A rechargeable battery that is easily replaced can recharge from any USB port and allows more than 17,000 barcode scans with a 1-second interval. With 8MB of onboard memory that stores over 400,000 UPC product barcodes or 60,000 product database records, memory shortages are no longer a concern.
The KDC280 comes with FREE KTSync® software and SDK for Android, iOS, and Windows devices. KTSync includes a keyboard wedging feature, application generation, DB lookup, inventory management, and KDC configuration features. SDK provides technical support from our top engineers and development team.
Description
The KDC280C-BLE features Bluetooth Low Energy to enable faster and simpler connection methods for use with smartwatches, smartglasses, and other smart devices.A built-in display and keypad eliminate blind erroneous data collection and enable interactive processes.
A rechargeable battery that is easily replaced can recharge from any USB port and allows more than 17,000 barcode scans with a 1-second interval. With 8MB of onboard memory that stores over 400,000 UPC product barcodes or 60,000 product database records, memory shortages are no longer a concern.
The KDC280 comes with FREE KTSync® software and SDK for Android, iOS, and Windows devices. KTSync includes a keyboard wedging feature, application generation, DB lookup, inventory management, and KDC configuration features. SDK provides technical support from our top engineers and development team.
Specifications
| Scanning | |
|---|---|
| Type | Built-in bar code reader |
| 2D (matrix & stacked) barcodes supported | Aztec Code, CodaBlockF, Data Matrix, MaxiCode, MicroPDF417, QR Code |
| Sensor type | Photo diode |
| Scanner type | 2D |
| Read rate (max) | 17000 reads/s |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Bluetooth version | 5.0 |
| Bluetooth Low Energy (BLE) | Yes |
| Standard interfaces | Bluetooth, USB |
| Performance | |
| International Protection (IP) code | IP65 |
| Internal memory | 8 MB |
| Product colour | Grey |
| Certification | R&TTE, FCC, KC, TELEC, VCCI, SRRC, RoHS |
| Design | |
| Type | Built-in bar code reader |
| International Protection (IP) code | IP65 |
| Product colour | Grey |
| Certification | R&TTE, FCC, KC, TELEC, VCCI, SRRC, RoHS |
| Power | |
| Power source type | Battery |
| Number of batteries supported | 1 |
| Battery voltage | 3.7 V |
| Battery type | Built-in battery |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 650 mAh |
| Weight & dimensions | |
| Width | 40 mm |
| Depth | 18 mm |
| Height | 82 mm |
| Weight | 57.5 g |
| Technical details | |
| Type | Built-in bar code reader |
| International Protection (IP) code | IP65 |
| Internal memory | 8 MB |
| Product colour | Grey |
| Certification | R&TTE, FCC, KC, TELEC, VCCI, SRRC, RoHS |
