Description
KDC180H 2D Imager Wearable Barcode Scanner & Data Collector
The KDC180 is IP65-rated and has a 6' drop spec. This means the device is dust tight and water-resistant; it's ideal for any environment.
Advanced power management puts the scanner in "hibernation mode" when not actively in use, allowing the battery to outlast an average work shift. When power does run out, easily charge the KDC via Micro USB cable or multibay charging cradle.
The KDC180 easily and securely integrates with wearable scanning solutions such as the Ring Scanner or Finger Trigger Glove. The 1" OLED display along with a set of 5 programmable LED indicators provides scan feedback to the user.
The KDC180 features Bluetooth® Low Energy (BLE5.0) to enable faster and simpler connection methods for use with smartwatches, smart glasses, and other wearable smart devices. BLE offers low power consumption and fast data transmission while maintaining an uncompromised connection.
The KDC180H is equipped with a 2D imager able to read all major barcode symbologies. The KDC180H provides more aggressive scanning for a variety of environments.
KTSync® software with keyboard wedging, application generation, database look up, inventory management, and KDC configuration features is included for Android, iOS, Mac OS X, Tizen, and Windows devices. Complementary SDK and technical support from top engineers and the development team ensure ease of data collection in any situation.
Description
The compact and lightweight KDC180 designed for use with KOAMTAC Ring Scanners or Finger Trigger Gloves to create the perfect wearable solution for your business. Charge your device via Micro USB cable or alongside other KOAMTAC products via pogo pins in our unique Multi-bay Charging Cradles.The KDC180 is IP65-rated and has a 6' drop spec. This means the device is dust tight and water-resistant; it's ideal for any environment.
Advanced power management puts the scanner in "hibernation mode" when not actively in use, allowing the battery to outlast an average work shift. When power does run out, easily charge the KDC via Micro USB cable or multibay charging cradle.
The KDC180 easily and securely integrates with wearable scanning solutions such as the Ring Scanner or Finger Trigger Glove. The 1" OLED display along with a set of 5 programmable LED indicators provides scan feedback to the user.
The KDC180 features Bluetooth® Low Energy (BLE5.0) to enable faster and simpler connection methods for use with smartwatches, smart glasses, and other wearable smart devices. BLE offers low power consumption and fast data transmission while maintaining an uncompromised connection.
The KDC180H is equipped with a 2D imager able to read all major barcode symbologies. The KDC180H provides more aggressive scanning for a variety of environments.
KTSync® software with keyboard wedging, application generation, database look up, inventory management, and KDC configuration features is included for Android, iOS, Mac OS X, Tizen, and Windows devices. Complementary SDK and technical support from top engineers and the development team ensure ease of data collection in any situation.
Specifications
| Scanning | |
|---|---|
| Type | Wearable bar code reader |
| 2D (matrix & stacked) barcodes supported | Aztec Code, CodaBlockF, Code 49, Data Matrix, Han Xin, MaxiCode, MicroPDF417, PDF417, QR Code |
| Scanner type | 2D |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Bluetooth version | 5.0 |
| Bluetooth Low Energy (BLE) | Yes |
| Standard interfaces | Bluetooth, USB |
| Performance | |
| Protection features | Drop resistant, Water resistant |
| Display technology | OLED |
| Built-in display | Yes |
| International Protection (IP) code | IP65 |
| Internal memory | 8 MB |
| Product colour | Black |
| Certification | RED, FCC, KC, TELEC, VCCI, SRRC, RoHS |
| Display diagonal | 2.54 cm (1") |
| Design | |
| Type | Wearable bar code reader |
| Protection features | Drop resistant, Water resistant |
| International Protection (IP) code | IP65 |
| Product colour | Black |
| Certification | RED, FCC, KC, TELEC, VCCI, SRRC, RoHS |
| Power | |
| Power source type | Battery |
| Number of batteries supported | 1 |
| Battery voltage | 3.7 V |
| Battery type | Built-in battery |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 1010 mAh |
| Weight & dimensions | |
| Width | 40 mm |
| Depth | 20.3 mm |
| Height | 69 mm |
| Weight | 65.3 g |
| Technical details | |
| Type | Wearable bar code reader |
| Protection features | Drop resistant, Water resistant |
| Display technology | OLED |
| Built-in display | Yes |
| International Protection (IP) code | IP65 |
| Internal memory | 8 MB |
| Product colour | Black |
| Certification | RED, FCC, KC, TELEC, VCCI, SRRC, RoHS |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
