Description
DONN06G 10-in-1 USB 3.2 Gen 1 Docking Station, HDMI, 100W USB PD, USB-C 5Gbps x 2, USB-A 5Gbps x 3, SD, TF/MicroSD, GbE
The adapter provides an easy way to add HDTV, or equipment such as a monitor or projector to any USB-C device such as a smartphone, portable gaming console, MacBook, Chromebook Pixel or any similar late-model laptop with USB-C ports. Perfect for home entertainment, office presentations and classroom teaching.
Key Features
- 10-in-1 USB-C to HDMI/GbE/USB-C PD/USB-C 5Gbps/USB-A 5Gbps/SD/TF multiport adapter
- Supports HDMI resolution up to 4K 30Hz
- Supports USB Power Delivery (PD) up to 100W
- Provides a Gigabit Ethernet port with speeds up to 1000Mbps
- Supports Wake-on-LAN feature to startup computers remotely
- Features SD 3.0 and MicroSD/TF 3.0 slots, supporting simultaneous reading and writing of two cards
- USB 3.2 Gen 1 SuperSpeed (5Gb/s)
- Multi-platform support: Windows, macOS, ChromeOS
- Simple Plug and Play installation
- Cable length: 20cm
- Aluminum casing for heat dissipation
Description
This 10-in-1 USB-C to HDMI Adapter makes it possible to expand your device’s USB Type-C capacity with HDMI/USB-C PD/USB-C 5Gbps/USB-A 5Gbps/GbE ports and card readers (SD, MicroSD/TF). The adapter allows you to connect to the internet easily through the built-in USB port on your laptop. This is an ideal solution for MacBook or other Windows computers that may have wireless built-in but don’t come with an Ethernet port.The adapter provides an easy way to add HDTV, or equipment such as a monitor or projector to any USB-C device such as a smartphone, portable gaming console, MacBook, Chromebook Pixel or any similar late-model laptop with USB-C ports. Perfect for home entertainment, office presentations and classroom teaching.
Specifications
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 3 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Microphone in | No |
| Headphone outputs | 0 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| Network | |
| Wake-on-LAN ready | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Maximum digital resolution | 3840 x 2160 pixels |
| Country of origin | China |
| Product colour | Grey |
| Card reader integrated | Yes |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| HD type | 4K Ultra HD |
| Housing material | Aluminium |
| Technical details | |
| Product colour | Grey |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Master (outer) cases per pallet | 30 pc(s) |
| Harmonized System (HS) code | 8517623500 |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 400 mm |
| Master (outer) case gross weight | 6.1 kg |
| Master (outer) case length | 220 mm |
| Master (outer) case height | 225 mm |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Power | |
| Power source type | USB |
| USB cable length | 0.2 m |
| Software | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma |
| Mobile operating systems supported | Android 10.0, Android 11.0, Android 12.0, Android 13.0, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 80 °C |
| Weight & dimensions | |
| Weight | 99 g |
| Width | 55.4 mm |
| Depth | 16.6 mm |
| Height | 125 mm |
| Package weight | 135 g |
| Package width | 95 mm |
| Package depth | 20 mm |
| Package height | 200 mm |
| Design | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma |
| Country of origin | China |
| Product colour | Grey |
| Packaging data | |
| Package weight | 135 g |
| Package width | 95 mm |
| Package depth | 20 mm |
| Package height | 200 mm |
| Packaging content | |
| Quick start guide | Yes |
| Logistics data | |
| Pallet gross width | 120 cm |
| Pallet gross length | 80 cm |
| Pallet gross height | 112.5 cm |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 400 mm |
| Master (outer) case gross weight | 6.1 kg |
| Master (outer) case length | 220 mm |
| Master (outer) case height | 225 mm |
| Harmonized System (HS) code | 8517623500 |
| Other features | |
| Master (outer) cases per pallet | 30 pc(s) |
