Description
DLP, XGA (1024 x 768), 4:3, 3700 lm, HDMI, VGA, RS232, USB, 316 x 244 x 108 mm, 3 Kg
Key Features
- Bright XGA projector - 3700 ANSI lumens
- Short throw lens - 100" image from just over a metre away
- Easy connectivity - HDMI, VGA, USB power
- Clear, powerful audio - 10W speaker
Description
Project bright, vibrant presentations effortlessly any time of day. Designed for small meeting rooms and classrooms, this short throw projector boasts amazing colour, a long lamp life and energy saving features for a lower overall cost of ownership.Specifications
| Projector | |
|---|---|
| Projector native resolution | XGA (1024x768) |
| Native aspect ratio | 4:3 |
| Supported aspect ratios | 4:3, 16:9 |
| Screen size compatibility | 810.3 - 6281.4 mm (31.9 - 247.3") |
| Projection distance | 0.4 - 3.1 m |
| Contrast ratio (typical) | 25000:1 |
| Vertical scan range | 50 - 85 Hz |
| Horizontal scan range | 15.38 - 91.15 kHz |
| Uniformity | 75% |
| Keystone correction, vertical | -40 - 40° |
| Projection technology | DLP |
| Projector brightness | 3700 ANSI lumens |
| Lamps | |
| Lamps quantity | 1 lamp(s) |
| Lamp power | 203 W |
| Light source type | Lamp |
| Service life of light source | 6000 h |
| Service life of light source (economic mode) | 10000 h |
| Light source | |
| Lamps quantity | 1 lamp(s) |
| Lamp power | 203 W |
| Light source type | Lamp |
| Service life of light source | 6000 h |
| Service life of light source (economic mode) | 10000 h |
| Lens system | |
| Fixed focal length | 7.15 mm |
| Throw ratio | 0.617:1 |
| Offset | 115% |
| Scanning frequency | |
| Vertical scan range | 50 - 85 Hz |
| Horizontal scan range | 15.38 - 91.15 kHz |
| Video | |
| Supported 3D formats | Frame packing, Side by side, Top and bottom |
| Analog signal format system | NTSC, NTSC 3.58, NTSC 4.43, NTSC J, NTSC M, PAL, PAL 4.43, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM 4.25/4.4, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L |
| Full HD | No |
| 3D | Yes |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080) |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
| Ports & interfaces | |
| HDMI connector type | Full-size |
| PC in (D-Sub) | Yes |
| HDMI version | 1.4a |
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Composite video in | 1 |
| Audio (L/R) in | 0 |
| S-Video inputs quantity | 0 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| PC Audio in | Yes |
| DVI port | No |
| Component video (YPbPr/YCbCr) in | 0 |
| AC (power) in | Yes |
| Network | |
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
| Storage | |
| Card reader integrated | No |
| Sound emission | |
| Noise level | 26 dB |
| Technical details | |
| PC in (D-Sub) | Yes |
| Product colour | White |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Farsi, Finnish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Turkish, Vietnamese |
| Lamp power | 203 W |
| Quantity per pack | 1 pc(s) |
| Performance | |
| Market positioning | Presentation |
| Password protection | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Farsi, Finnish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Turkish, Vietnamese |
| Vertical scan range | 50 - 85 Hz |
| Horizontal scan range | 15.38 - 91.15 kHz |
| Noise level | 26 dB |
| Number of OSD languages | 25 |
| Features | |
| Password protection | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Farsi, Finnish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Turkish, Vietnamese |
| Noise level | 26 dB |
| Number of OSD languages | 25 |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
| Design | |
| Market positioning | Presentation |
| Product type | Short throw projector |
| Cable lock slot type | Kensington |
| Product colour | White |
| Cable lock slot | Yes |
| Placement | Desktop, Ceiling |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 225 W |
| Power source | AC |
| Power consumption (typical) | 187 W |
| Power consumption (standby) | 0.5 W |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Supplier features | |
| Harmonized System (HS) code | 85286200 |
| Weight & dimensions | |
| Weight | 3 kg |
| Width | 316 mm |
| Depth | 244 mm |
| Height | 108 mm |
| Packaging content | |
| Remote control included | Yes |
| Manual | Yes |
| Cables included | AC |
| Batteries included | Yes |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 85286200 |
