Dual-band, IEEE 802.11ac/n/a, 5 GHz: 867 Mbps, MU-MIMO
Key Features
- Faster AC Wi-Fi—AC1200 dual-band is ideal for 4K video streaming and high-speed downloading
- Far-Reaching Coverage—4× antennas and Beamforming delivers extensive Wi-Fi coverage and reliable connections
- Multi-Mode 3-in-1—Supports Router, Access Point, and Range Extender modes for added flexibility
- Parental Controls—Manages when and how connected devices can access the internet
- Guest Network—Provides separate access for guests in order to secure the host network
- Smooth HD Streaming—Supports IGMP Proxy/Snooping, Bridge, and Tag VLAN to optimize IPTV streaming
- IPv6 Supported—Compatible with the IPv6 (the latest Internet Protocol version 6)
- Compact and Mountable—Designed to conserve space and complement any décor
Description
Fast Dual-Band WiFi
Dual-band Wi-Fi allows you to connect your demanding devices to the faster and clearer 5 GHz band, while a tradition 2.4 GHz band provides a far-reaching, stable connection to the rest of your devices.
Boosted Signal throughout Your Home
Access your entertainment from every corner of your home with 4 external high-performance antennas. Beamforming technology detects devices and concentrates wireless signals towards them, even if they are far away or low-powered.
Talk to Devices Simultaneously
Equipped with MU-MIMO technology to connect more devices and maintain low latency. Concurrent streamings on 2 different MU-MIMO devices now will just be smooth as connecting only one, as long as you have enough bandwidth from your ISP.
Router Mode (Default)
Plug in an Ethernet cable to instantly create a private wireless network and share internet access with all your Wi-Fi devices.
Access Point Mode
Transform your existing wired network into a wireless one.
Range Extender Mode
Boost the existing wireless coverage in your house.
Versatile Management
Easily manage your home network with versatile built-in tools, including Parental Controls, Guest Network, QoS, and more.
Specifications
| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| DSL features |
|---|
| DSL WAN |
Yes |
| Mobile network |
|---|
| SIM card slot |
No |
| 3G |
No |
| 4G |
No |
| Protocols |
|---|
| DMZ support |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Management features |
|---|
| Universal Plug and Play (UPnP) |
Yes |
| WPS push button |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| MU-MIMO technology |
Yes |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| Wireless LAN features |
|---|
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) |
867 Mbit/s |
| WLAN data transfer rate (second band) |
300 Mbit/s |
| Network |
|---|
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Port triggering |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
4 |
| Security |
|---|
| Security algorithms |
WEP, WPA, WPA2, WPA2-Enterprise |
| Firewall |
Yes |
| DMZ support |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Access Control List (ACL) |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| Product colour |
Black |
| Antenna |
|---|
| Antenna design |
External |
| Antennas quantity |
4 |
| Power |
|---|
| Power source type |
AC |
| Output voltage |
9 V |
| Output current |
0.85 A |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-40 - 60 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
115 mm |
| Height |
24.3 mm |
| Depth |
106.7 mm |
