Description
300 m max, HomePlug AV2, IEEE 802.3, IEEE 802.3u, IEEE802.11b/g/n, OFDM (PLC), 128-bit AES, 112 x 84.7 x 39 mm
Extend WiFi to Every Corner
of Your Home
AV1000 Gigabit Powerline WiFi Kit
Where there’s an Outlet, There’s WiFi.
The MP510 Kit transmits network data through your existing electrical circuit, which prominently avoids the influence of obstacles on your WiFi. Enjoy extended WiFi wherever you need it with a transmission range of up to 300 meters on the same electrical circuit—perfect for your daily WiFi use.
Dual Gigabit Transmissions
Fast. Unlimited. Enjoyable.
Equipped with advanced HomePlug AV2 technology, your Powerline transmission rate reaches an ultra-fast 1000 Mbps. The included gigabit port helps you receive a high-quality network from any one of your outlets.
Plug & Play
With factory pre-configuration, you can immediately extend your network without complex wiring and configuration as soon as you connect one MP500 to your router and plug the MP510 extender into an outlet wherever you need network service.
Unify Your WiFi Network
Press the WPS Button on your router and the WiFi Clone Button on the MP510 to copy your router’s SSID and password to create a single, unified WiFi network throughout your home. Any setting changes will be automatically applied to the entire Powerline network.
Easy Expansion to Fit Every Type of Home
If a typical two-pack kit doesn’t meet all your networking needs, simply add more Powerline adapters to expand your WiFi to any room.
Key Features
- Eliminate WiFi Dead Zones — Extend 300 Mbps WiFi wherever you need via your home’s existing wiring
- 1000 Mbps High-Speed Transfer Rate — Fast and stable transmissions with advanced HomePlug AV2
- Super-Fast Wired Connections — A gigabit port for PCs, IPTVs, and game consoles
- Plug & Play — Say goodbye to complex wiring and configuration, just plug and play
- Easy Expansion — Expand coverage by simply adding more Powerline adapters
Description
4K Streaming MateExtend WiFi to Every Corner
of Your Home
AV1000 Gigabit Powerline WiFi Kit
Where there’s an Outlet, There’s WiFi.
The MP510 Kit transmits network data through your existing electrical circuit, which prominently avoids the influence of obstacles on your WiFi. Enjoy extended WiFi wherever you need it with a transmission range of up to 300 meters on the same electrical circuit—perfect for your daily WiFi use.
Dual Gigabit Transmissions
Fast. Unlimited. Enjoyable.
Equipped with advanced HomePlug AV2 technology, your Powerline transmission rate reaches an ultra-fast 1000 Mbps. The included gigabit port helps you receive a high-quality network from any one of your outlets.
Plug & Play
With factory pre-configuration, you can immediately extend your network without complex wiring and configuration as soon as you connect one MP500 to your router and plug the MP510 extender into an outlet wherever you need network service.
Unify Your WiFi Network
Press the WPS Button on your router and the WiFi Clone Button on the MP510 to copy your router’s SSID and password to create a single, unified WiFi network throughout your home. Any setting changes will be automatically applied to the entire Powerline network.
Easy Expansion to Fit Every Type of Home
If a typical two-pack kit doesn’t meet all your networking needs, simply add more Powerline adapters to expand your WiFi to any room.
Specifications
| Performance | |
|---|---|
| Ethernet LAN interface type | Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
| Built-in power socket | No |
| PowerLine standard | HomePlug AV2 |
| Modulation | OFDM |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3-PSK |
| Maximum operating distance | 300 m |
| Encryption button | Yes |
| Plug and Play | Yes |
| Technical details | |
| Antenna type | External |
| Ethernet LAN interface type | Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
| Built-in power socket | No |
| PowerLine standard | HomePlug AV2 |
| Modulation | OFDM |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3-PSK |
| Maximum operating distance | 300 m |
| LED indicators | Yes |
| Encryption button | Yes |
| Product colour | White |
| Plug and Play | Yes |
| Certification | CE |
| Harmonized System (HS) code | 85171800 |
| Power | |
| Power consumption (typical) | 4.29 W |
| Design | |
| Antenna type | External |
| LED indicators | Yes |
| Product colour | White |
| Certification | CE |
| Antennas quantity | 2 |
| System requirements | |
| Mac compatibility | Yes |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 112 mm |
| Depth | 84.7 mm |
| Height | 39 mm |
| Packaging content | |
| Manual | Yes |
| Quantity per pack | 2 pc(s) |
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
| Logistics data | |
| Harmonized System (HS) code | 85171800 |
