Description
Line-Interactive, 750VA, 450W, 1 x C14 In, 4 x C13 Out, USB, RS-232, EPO, Intelligent Slot, UK
The PowerWalker VI R1U is a flexible all-rounder for home and semi-professional environments.
Key Features
- Slim 1U design
- USB with Human Interface Device (HID) support and Intelligent Slot for communication cards
- Pure Sine Wave for wide range of applications and harsh environment
- Auto dimming screen (UPS is woken up with mute button)
Description
The PowerWalker VI R1U is a line interactive 1U rack UPS solution. Thanks to its 1U design, the UPS fits in nearly every setting. It is equipped with pure sine wave output and an optional card slot for network cards, so that even sensitive and critical loads can be kept safe.The PowerWalker VI R1U is a flexible all-rounder for home and semi-professional environments.
Specifications
| Power | |
|---|---|
| Output voltage regulation | 10% |
| Output frequency regulation | 0.5 Hz |
| Output power factor | 0.6 |
| Output power | 450 W |
| Input operation voltage (min) | 165 V |
| Input operation voltage (max) | 290 V |
| Efficiency | 95% |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.6 |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Output power capacity | 0.75 kVA |
| Charging current | 1 A |
| Performance | |
| UPS topology | Line-Interactive |
| Waveform | Pure sine |
| Response time | 4 ms |
| LED indicators | Yes |
| Features | |
| UPS topology | Line-Interactive |
| Waveform | Pure sine |
| Output voltage regulation | 10% |
| Output frequency regulation | 0.5 Hz |
| Output power factor | 0.6 |
| Response time | 4 ms |
| Output power | 450 W |
| Input operation voltage (min) | 165 V |
| Input operation voltage (max) | 290 V |
| Efficiency | 95% |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.6 |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Output power capacity | 0.75 kVA |
| Input frequency | 50/60 Hz |
| Charging current | 1 A |
| Ports & interfaces | |
| Emergency Power Off (EPO) connector | Yes |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| SmartSlot | Yes |
| AC outlets quantity | 4 AC outlet(s) |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| RS-232 ports | 1 |
| USB port type | USB Type-B |
| Battery | |
| Number of batteries supported | 2 |
| Battery voltage | 6 V |
| Battery capacity | 9 Ah |
| Battery recharge time | 8 h |
| Typical backup time at half load | 8.7 min |
| Typical backup time at full load | 0.4 min |
| Charging current | 1 A |
| Design | |
| Rack capacity | 1U |
| Form factor | Rackmount/Tower |
| LED indicators | Yes |
| Product colour | Black |
| Built-in fan | No |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Technical details | |
| Sustainability compliance | Yes |
| Sustainability certificates | ENERGY STAR |
| Harmonized System (HS) code | 85078000 |
| Cooling | |
| Built-in fan | No |
| Weight & dimensions | |
| Weight | 8.6 kg |
| Width | 433 mm |
| Height | 44 mm |
| Depth | 216 mm |
| Battery width | 53.7 cm |
| Battery depth | 31.7 cm |
| Battery height | 15 cm |
| Battery weight | 9.8 kg |
| Packaging data | |
| Cables included | Input power cable, USB cable |
| Rack mount kit | Yes |
| Manual | Yes |
| Bundled software | PowerMaster |
| Other features | |
| Nominal output voltage | 230 V |
| Packaging content | |
| Cables included | Input power cable, USB cable |
| Rack mount kit | Yes |
| Manual | Yes |
| Bundled software | PowerMaster |
