Description
SSDPEKNU010TZX1
Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Intel® Rapid Start Technology
Intel® Rapid Start Technology allows quick system resumes from the hibernate state.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
Intel® Smart Response Technology
Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive.
High Endurance Technology (HET)
High Endurance Technology (HET) in SSD's combines Intel® NAND Flash Memory silicon enhancements and SSD system management techniques to help extend the endurance of the SSD. Endurance is defined as the amount of data that can be written to an SSD during its lifetime.
Intel® Remote Secure Erase
Intel® Remote Secure Erase provides IT administrators a secure method for remotely wiping an Intel SSD from a familiar management console when retiring or repurposing a system. This allows for immediate re-use while saving administrative time and costs.
Description
Enhanced Power Loss Data ProtectionEnhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Intel® Rapid Start Technology
Intel® Rapid Start Technology allows quick system resumes from the hibernate state.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
Intel® Smart Response Technology
Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive.
High Endurance Technology (HET)
High Endurance Technology (HET) in SSD's combines Intel® NAND Flash Memory silicon enhancements and SSD system management techniques to help extend the endurance of the SSD. Endurance is defined as the amount of data that can be written to an SSD during its lifetime.
Intel® Remote Secure Erase
Intel® Remote Secure Erase provides IT administrators a secure method for remotely wiping an Intel SSD from a familiar management console when retiring or repurposing a system. This allows for immediate re-use while saving administrative time and costs.
Specifications
| Hard drive | |
|---|---|
| SSD capacity | 1 TB |
| Memory type | 3D4 QLC |
| Performance | |
| Intel® Smart Response Technology | Yes |
| Intel® Rapid Start Technology | Yes |
| Intel High Endurance Technology (HET) | No |
| Interface | PCI Express 3.0 |
| Component for | PC/Laptop |
| SSD ARK ID | 204109 |
| NVMe | Yes |
| TBW rating | 370 |
| End-to-End Data Protection | Yes |
| SSD capacity | 1 TB |
| Security algorithms | 256-bit AES |
| Memory type | 3D4 QLC |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| SSD temperature monitoring | No |
| Mean time between failures (MTBF) | 1600000 h |
| Hardware encryption | Yes |
| Enhanced Power Loss Data Protection technology | No |
| Security | |
| Security algorithms | 256-bit AES |
| Endurance | |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| Mean time between failures (MTBF) | 1600000 h |
| Design | |
| Component for | PC/Laptop |
| SSD form factor | M.2 |
| Features | |
| Interface | PCI Express 3.0 |
| Component for | PC/Laptop |
| SSD ARK ID | 204109 |
| NVMe | Yes |
| TBW rating | 370 |
| End-to-End Data Protection | Yes |
| SSD capacity | 1 TB |
| Security algorithms | 256-bit AES |
| Memory type | 3D4 QLC |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| SSD temperature monitoring | No |
| Mean time between failures (MTBF) | 1600000 h |
| Hardware encryption | Yes |
| Enhanced Power Loss Data Protection technology | No |
| SSD form factor | M.2 |
| Harmonized System (HS) code | 84717070 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G182471 |
| Use conditions | PC/Client/Tablet |
| Power | |
| Power consumption (idle) | 0.025 W |
| Brand-specific features | |
| Intel® Smart Response Technology | Yes |
| Intel® Rapid Start Technology | Yes |
| Intel High Endurance Technology (HET) | No |
| Intel® Remote Secure Erase | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Maximum operating temperature | 70 °C |
| Technical details | |
| Interface | PCI Express 3.0 |
| Operating temperature (T-T) | 0 - 70 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| SSD temperature monitoring | No |
| Internal memory type | PCIe 3.0 x4, NVMe |
| Intel High Endurance Technology (HET) | No |
| Hardware encryption | Yes |
| Enhanced Power Loss Data Protection technology | No |
| Power consumption (active) | 0.08 W |
| SSD form factor | M.2 |
| Processor family | Intel SSD 6 |
| Status | Launched |
| SSD shock | 1000G,0.5msOper/ing---1500G,0.5msnon-oper/ing |
| SSD endurance rating | 370 |
| Sequential writing speed | 2500 MB/s |
| Sequential reading | 3500 MB/s |
| Random write (8GB span) | 330000 IOPS |
| Launch date | Q1'21 |
| Random read (8GB span) | 220000 IOPS |
| Weight & dimensions | |
| Width | 80 mm |
| Height | 22 mm |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
| Other features | |
| Processor family | Intel SSD 6 |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| Internal memory type | PCIe 3.0 x4, NVMe |
| Power consumption (active) | 0.08 W |
| Status | Launched |
| SSD shock | 1000G,0.5msOper/ing---1500G,0.5msnon-oper/ing |
| SSD endurance rating | 370 |
| Sequential writing speed | 2500 MB/s |
| Sequential reading | 3500 MB/s |
| Random write (8GB span) | 330000 IOPS |
| Launch date | Q1'21 |
| Random read (8GB span) | 220000 IOPS |
