Description
USB 3.0 Type A, 2.4GHz/5GHz, WEP 64/128-bit, WPA, WPA2
Key Features
- Supports Wave-2 compliant MU-MIMO
- Supports WPS (Wi-Fi Protected Setup) hardware button for easy connection
- Supports WMM QoS feature
- MAX. data transfer rate up to 300Mbps (2.4GHz) or up to 867Mbps (5GHz)
- Dual-band wireless connectivity for 2.4GHz or 5GHz
- Adjustable antenna for optimum Wi-Fi performance
Description
802.11ac | Super Speed The EW-7822UAD runs ultra-speed 802.11ac Wi-Fi that’s almost three times faster than 802.11n. Upgrade your laptop or PC to 802.11ac Wi-Fi so you can enjoy online video streaming and multiple data transfers at the fastest speeds. The EW-7822UAD is certainly a powerful and easy-to-use gadget for upgrading your existing wireless network to the next AC level. USB 3.0 Port | Faster than Ever USB 3.0 is up to 10 times faster than USB 2.0 with data transfer rates up to 5Gbps. It’s the latest standard in connectivity and enables devices to achieve the superfast speeds which 802.11ac can provide – for faster photos, music, videos, and data. Dual Mode | Double your Fun Experience better performance and greater flexibility with EW-7822UAD for your laptop with dual-band connectivity. Either the 2.4GHz or 5GHz frequency band can be selected with top speeds at 300Mbps and 867Mbps respectively. Surf the internet and check emails on the longer-range 2.4GHz band, or use the high-speed 5GHz band for online gaming and YouTube or Netflix HD streaming. 11ac MU-MIMO | Enjoy Non-Stop No more wait time at highest throughput. The latest 11ac MU-MIMO (Multiple User - Multiple Input Multiple Output) technology runs four streams and serve multiple devices simultaneously, for the fastest speeds and uninterrupted Wi-Fi connectivity to all devices. MU-MIMO | More Streams Instantly upgrades your older laptop or PC to the latest 11ac MU-MIMO functionality. Everyone in the room can enjoy smooth surfing, streaming and gaming at the same time when the EW-7822UAD is successfully paired with a MU-MIMO router. Adjustable Antenna | Optimize Your Wi-Fi Need to stretch your Wi-Fi signal? You can adjust the antenna of the EW-7822UAD perpendicularly or horizontally to spread out Wi-Fi at wish. It can be plugged into any laptop or comouter for more mobility and convenience, and looks great.Specifications
| Ports & interfaces | |
|---|---|
| Internal | No |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Interface | WLAN |
| Host interface | USB |
| Connectivity technology | Wireless |
| Bandwidth | |
| Maximum data transfer rate | 867 Mbit/s |
| Wireless LAN features | |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| WLAN data transfer rates supported | 1,2,5.5,6,9,11,12,24,36,48,54,144,300,867 Mbit/s |
| Antenna | |
| Antenna | Yes |
| Technical details | |
| Product colour | Black |
| Receiver sensitivity | 2.4GHz: 11b(11M): -80±2dBm, 11g(54M): -68±2dBm, 11n(20MHz, MCS7): -66±2dBm, 11n(40MHz, MCS7): -65±2dBm 5GHz: 11a(54M): -68±2dBm, 11n(20MHz, MCS7): -65±2dBm, 11n(40MHz, MCS7): -62±2dBm, 11ac(80MHz, VHTMCS9): -52±2dBm |
| Harmonized System (HS) code | 85176990 |
| Network | |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2, WPS |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n |
| WLAN data transfer rates supported | 1,2,5.5,6,9,11,12,24,36,48,54,144,300,867 Mbit/s |
| Maximum data transfer rate | 867 Mbit/s |
| Receiver sensitivity | 2.4GHz: 11b(11M): -80±2dBm, 11g(54M): -68±2dBm, 11n(20MHz, MCS7): -66±2dBm, 11n(40MHz, MCS7): -65±2dBm 5GHz: 11a(54M): -68±2dBm, 11n(20MHz, MCS7): -65±2dBm, 11n(40MHz, MCS7): -62±2dBm, 11ac(80MHz, VHTMCS9): -52±2dBm |
| Design | |
| Product colour | Black |
| Antenna | Yes |
| Certification | CE FCC NCC BSMI |
| Internal | No |
| Receiver sensitivity | 2.4GHz: 11b(11M): -80±2dBm, 11g(54M): -68±2dBm, 11n(20MHz, MCS7): -66±2dBm, 11n(40MHz, MCS7): -65±2dBm 5GHz: 11a(54M): -68±2dBm, 11n(20MHz, MCS7): -65±2dBm, 11n(40MHz, MCS7): -62±2dBm, 11ac(80MHz, VHTMCS9): -52±2dBm |
| Antenna design | External |
| Software | |
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| System requirements | |
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 18 mm |
| Depth | 174.5 mm |
| Height | 14.4 mm |
| Weight | 15 g |
| Security | |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2, WPS |
| Performance | |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2, WPS |
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Receiver sensitivity | 2.4GHz: 11b(11M): -80±2dBm, 11g(54M): -68±2dBm, 11n(20MHz, MCS7): -66±2dBm, 11n(40MHz, MCS7): -65±2dBm 5GHz: 11a(54M): -68±2dBm, 11n(20MHz, MCS7): -65±2dBm, 11n(40MHz, MCS7): -62±2dBm, 11ac(80MHz, VHTMCS9): -52±2dBm |
| Certificates | |
| Certification | CE FCC NCC BSMI |
| Other features | |
| Receiver sensitivity | 2.4GHz: 11b(11M): -80±2dBm, 11g(54M): -68±2dBm, 11n(20MHz, MCS7): -66±2dBm, 11n(40MHz, MCS7): -65±2dBm 5GHz: 11a(54M): -68±2dBm, 11n(20MHz, MCS7): -65±2dBm, 11n(40MHz, MCS7): -62±2dBm, 11ac(80MHz, VHTMCS9): -52±2dBm |
| Harmonized System (HS) code | 85176990 |
