Description
Full HD Standard Signage, 32", 1920 x 1080 px, IPS, 400 cd/m², 10 ms, 178°/178°, HDMI, USB, RJ-45, black
LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
Compatible with AV Control System
The SM5J series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
LG's Simple Advertisement Helper, Promota
Using LG's Promota application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.
Real-Time Promotion
With Beacon and Bluetooth Low Energy (BLE), shop managers can provide coupons and information in real-time.
Content Sharing
Content Mirroring among devices is available on a Wi-Fi network.
Wireless Access Point
The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.
Key Features
- Brightness(Typ.) : 400 cd/m²
- Bezel : 13 mm (T/R/L), 18 mm (B)
- Depth : 55.5 mm
- Interface : HDMI(3) / USB 2.0 / RS232C / RJ45 / IR / Audio Out
- Built-in Speaker : 10W + 10W
Description
Various Sensor ConnectionLG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
Compatible with AV Control System
The SM5J series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
LG's Simple Advertisement Helper, Promota
Using LG's Promota application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.
Real-Time Promotion
With Beacon and Bluetooth Low Energy (BLE), shop managers can provide coupons and information in real-time.
Content Sharing
Content Mirroring among devices is available on a Wi-Fi network.
Wireless Access Point
The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.
Specifications
| Display | |
|---|---|
| Display number of colours | 16.7 million colours |
| Display technology | IPS |
| Display diagonal | 81.3 cm (32") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 400 cd/m² |
| HD type | Full HD |
| Response time | 10 ms |
| Contrast ratio (typical) | 1100:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Haze rate | 1% |
| Ports & interfaces | |
| Remote (IR) input | 1 |
| USB port | Yes |
| RS-232C | Yes |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0 |
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Built-in speaker(s) | Yes |
| Design | |
| Product design | Digital signage flat panel |
| Orientation | Horizontal/Vertical |
| Bezel width (top) | 1.3 cm |
| Bezel width (side) | 1.3 cm |
| Bezel width (bottom) | 1.8 cm |
| Product colour | Black |
| Panel mounting interface | 200 x 200 mm |
| VESA mounting | Yes |
| Performance | |
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| Ambient light sensor | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| Wi-Fi | Yes |
| Power | |
| Heat dissipation | 187.67 BTU/h |
| Power consumption (typical) | 55 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width (with stand) | 729.4 mm |
| Height (with stand) | 481 mm |
| Depth (with stand) | 154.2 mm |
| Weight (with stand) | 6.5 kg |
| Display width | 729.4 mm |
| Display depth | 55.5 mm |
| Display height | 428.9 mm |
| Display weight | 5.7 kg |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC, HDMI |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Technical details | |
| VESA mounting | Yes |
| Ambient light sensor | Yes |
| Weight (with stand) | 6.5 kg |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Packaging data | |
| Remote control included | Yes |
| Cables included | AC, HDMI |
| Features | |
| Harmonized System (HS) code | 85285210 |
| Other features | |
| Wi-Fi | Yes |
| Width (with stand) | 729.4 mm |
| Height (with stand) | 481 mm |
| Display technology | IPS |
| Depth (with stand) | 154.2 mm |
| Bezel width (top) | 1.3 cm |
| Bezel width (side) | 1.3 cm |
| Bezel width (bottom) | 1.8 cm |
| Weight (with stand) | 6.5 kg |
