Fibre cable 12 x OM3 LSZH indoor/outdoor 100m
Key Features
- Number of fibers: 12
- Fibre size: 50μm
- Color: Aqua
- Usage: Indoor/Outdoor
Description
Mainly used in data installations as backbone cabling. This cable is suitable for indoor and outdoor installations. For outdoor installations conduit have to be used. Designed for 10 Gigabit.
Specifications
| Technical details |
|---|
| Jacket material |
Low smoke zero halogen (LSZH) |
| Connector 1 |
No |
| Connector 2 |
No |
| Cable length |
100 m |
| Core diameter |
50 µm |
| Tube diameter |
3.2 mm |
| Number of optical fibres |
12 |
| Doesn't contain |
Halogen |
| Features |
|---|
| Compressive strength |
1500 |
| Bending radius |
14 cm |
| Fibre optic type |
OM3 |
| Jacket material |
Low smoke zero halogen (LSZH) |
| Connector 1 |
No |
| Connector 2 |
No |
| Cable length |
100 m |
| Core diameter |
50 µm |
| Operating temperature (T-T) |
-30 - 70 °C |
| Certification |
UNE-EN 50266 (IEC 60332-3), UNE-EN 50267 (IEC 60754-1), UNE-EN 50268 (IEC 61034- 1/2), EN 187000, CB 60794 |
| Wavelengths supported |
850 nm |
| Harmonized System (HS) code |
85447000 |
| Product colour |
Aqua colour |
| Connector 2 gender |
No |
| Connector 1 gender |
No |
| Certificates |
|---|
| Certification |
UNE-EN 50266 (IEC 60332-3), UNE-EN 50267 (IEC 60754-1), UNE-EN 50268 (IEC 61034- 1/2), EN 187000, CB 60794 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 70 °C |
| Weight & dimensions |
|---|
| Cable weight |
53 kg/km |
| Bending radius |
14 cm |
| Cable length |
100 m |
| Cable diameter |
7 mm |
| Weight |
3.9 kg |
| Package weight |
4 kg |
| Packaging data |
|---|
| Package weight |
4 kg |
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Harmonized System (HS) code |
85447000 |
| Quantity per pack |
1 pc(s) |
| Other features |
|---|
| Tube diameter |
3.2 mm |
| Number of optical fibres |
12 |
