receiver, 1920x1200 @ 60Hz, DVI-D, USB, RS-232, 3.5mm, 198x44x150 mm
Key Features
- Perfect digital video: uncompressed video extension and pixel perfect digital video up to 24 bits per color at a maximum of 1920x1200 over 60Hz with real time control
- Digital Stereo Audio: digitally delivered crystal clear audio across the network
- Distribution: DVI, USB, audio and bidirectional RS232 across up to 10km
- Power redundancy: the units can detect whether the network is in operation and will utilize the second network port is failure detected
- EDID management: Extended Display Identification Data (EDID) enables the remote system to exactly mirror the date coming from the source monitor
- Plug and Play: the ADDERLink INFINITY range is delivered in a zero config state so they work as soon as they are connected, without the need for drivers or software
- Robust yet lightweight: small form factor, rack mountable device
- USB True Emulation: USB 2.0 enables connection to any USB human interface device from mice and keyboards through to graphics tablets, jog shuttles, joysticks and 3D explorers
Description
Part of the ADDERLink INFINITY range, the ADDERLink INFINITY Dual 2020 is a high performance KVM solution that enables you to isolate critical computing hardware in a secure and temperature controlled environment. Configurable as a single link or dual head, this extender provides an ‘at-the-PC’ experience across up to 10km: the digital video you receive is the same as the digital video leaving the remote computer, with no loss of compression and minimal lag. The Dual 2020 comes with a choice of single mode or multimode fiber modules to suit your specific application. This KVM extender can be used as a point to point extender or can be integrated into a wider matrix system when combined with the ADDERLink INFINITY Manager (A.I.M.)
Specifications
| Features |
|---|
| Material |
Metal |
| Rack mounting |
Yes |
| Maximum refresh rate |
60 Hz |
| Certification |
CE, FCC |
| Type |
AV receiver |
| Maximum resolution |
1920 x 1200 pixels |
| Product colour |
Black |
| Technical details |
|---|
| Material |
Metal |
| Rack mounting |
Yes |
| Maximum refresh rate |
60 Hz |
| Certification |
CE, FCC |
| Type |
AV receiver |
| Maximum resolution |
1920 x 1200 pixels |
| Product colour |
Black |
| Connectivity technology |
Wired |
| Ports & interfaces |
|---|
| 3.5 mm (1/8-inch) out |
Yes |
| 3.5 mm (1/8-inch) in |
Yes |
| USB ports quantity |
4 |
| RS-232 input ports |
1 |
| USB connector type |
USB Type-A |
| DVI input ports |
2 |
| DC-in jack |
Yes |
| Connectivity technology |
Wired |
| Power |
|---|
| Input current |
0.8 A |
| AC input voltage |
100-240 V |
| AC input frequency |
50 - 60 Hz |
| Operating voltage |
5 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Width |
198 mm |
| Height |
44 mm |
| Depth |
150 mm |
| Weight |
1.1 kg |
| Packaging content |
|---|
| AC adapter included |
Yes |
