Description
Dual Radio Wi-Fi 6 (802.11ax) Access Point up to 1.7 Gbit/s, parallel operation in 2.4 GHz und 5 GHz, 2x2 MU-MIMO, OFMDA, BLE 5.1, 1x1GE, PoE 802.3at, internal antennas, WPA3, IEEE 802.1X, Multi-SSID, VLAN, internal antennas, incl. PSU
With the LANCOM LX-6200, you get high-throughput performance from the latest Wi-Fi 6 generation. This makes it the ideal device wherever the fastest Wi-Fi is needed for a small to medium-sized number of users, such as in hotels, smaller offices, medical practices, or branch offices. The integrated USB interface (2.0) also provides the basis for integrating IoT wireless systems into existing WLAN infrastructures.
Advantages
Dual concurrent Wi-Fi with an aggregated datarate of up to 1,775 Mbps
The LANCOM LX-6200 offers the Wi-Fi 6 standard (IEEE 802.11ax) for fast wireless LAN for clients in the 2.4- and 5-GHz bands. Wi-Fi 6 technology achieves transmission rates of up to 1,200 Mbps at 5 GHz and simultaneously up to 575 Mbps at 2.4 GHz.
2x2 Multi-User MIMO for downlinks and uplinks
Multi-user MIMO (MU-MIMO for short) simultaneously distributes all of the available spatial streams of the LANCOM LX-6200 between several different clients, rather than one after the other as was formerly the case. The available bandwidth is used efficiently and delays in the wireless network are substantially reduced. With Wi-Fi 6, MU-MIMO is not, as before, only usable in the downlink but now also in the uplink as well.
Professional IoT support via BLE and USB
With the LANCOM LX-6200, you can easily dive into the world of the Internet-of-Things (IoT). Support for Bluetooth Low Energy (5.1) and USB 2.0 opens up many possibilities for you to communicate with modern WLAN sensors in devices or objects and use innovative applications such as asset tracking or digital signage.. In this way, you can easily operate solutions for digital signage, electronic shelf labels, and industrial Internet of things applications via the optionally available LANCOM Wireless ePaper USB.
Managed via LANCOM Management Cloud, WLAN controller, or stand-alone
The LANCOM LX-6200 offers the greatest possible versatility in operation: Managed through the LANCOM Management Cloud, it integrates into a holistic, automated network orchestration system based on software-defined networking technology. It is also able to operate with central management by LANCOM WLAN controller or even in stand-alone mode.
Wi-Fi security standard WPA3
WPA3, the successor of WPA2, offers important upgrades and security features for small ("WPA3-Personal") and large networks ("WPA3-Enterprise").
Key Features
- Dual concurrent Wi-Fi – parallel operation at 2.4 GHz and 5 GHz with Wi-Fi 6 (IEEE 802.11ax)
- 2x2 multi-user MIMO for simultaneous beam-steering for multiple clients in down- an uplink mode
- USB 2.0 port for connecting wireless IoT systems
- 5.1 Bluetooth Low Energy radio module
- Automated operation via the LANCOM Management Cloud (LMC)
- WLAN controller support (including layer-3 tunneling)
- Support of the security standard WPA3
- Uncompromising and future-proof standards for replacement service, manufacturer support, and lifecycle management
- Suitable for use with medical electrical equipment in a non-life-supporting environment (EN 60601-1-2)
Description
Fast Wi-Fi 6 for small and medium user densitiesWith the LANCOM LX-6200, you get high-throughput performance from the latest Wi-Fi 6 generation. This makes it the ideal device wherever the fastest Wi-Fi is needed for a small to medium-sized number of users, such as in hotels, smaller offices, medical practices, or branch offices. The integrated USB interface (2.0) also provides the basis for integrating IoT wireless systems into existing WLAN infrastructures.
Advantages
Dual concurrent Wi-Fi with an aggregated datarate of up to 1,775 Mbps
The LANCOM LX-6200 offers the Wi-Fi 6 standard (IEEE 802.11ax) for fast wireless LAN for clients in the 2.4- and 5-GHz bands. Wi-Fi 6 technology achieves transmission rates of up to 1,200 Mbps at 5 GHz and simultaneously up to 575 Mbps at 2.4 GHz.
2x2 Multi-User MIMO for downlinks and uplinks
Multi-user MIMO (MU-MIMO for short) simultaneously distributes all of the available spatial streams of the LANCOM LX-6200 between several different clients, rather than one after the other as was formerly the case. The available bandwidth is used efficiently and delays in the wireless network are substantially reduced. With Wi-Fi 6, MU-MIMO is not, as before, only usable in the downlink but now also in the uplink as well.
Professional IoT support via BLE and USB
With the LANCOM LX-6200, you can easily dive into the world of the Internet-of-Things (IoT). Support for Bluetooth Low Energy (5.1) and USB 2.0 opens up many possibilities for you to communicate with modern WLAN sensors in devices or objects and use innovative applications such as asset tracking or digital signage.. In this way, you can easily operate solutions for digital signage, electronic shelf labels, and industrial Internet of things applications via the optionally available LANCOM Wireless ePaper USB.
Managed via LANCOM Management Cloud, WLAN controller, or stand-alone
The LANCOM LX-6200 offers the greatest possible versatility in operation: Managed through the LANCOM Management Cloud, it integrates into a holistic, automated network orchestration system based on software-defined networking technology. It is also able to operate with central management by LANCOM WLAN controller or even in stand-alone mode.
Wi-Fi security standard WPA3
WPA3, the successor of WPA2, offers important upgrades and security features for small ("WPA3-Personal") and large networks ("WPA3-Enterprise").
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Syslog | Yes |
| Country of origin | Germany |
| Web-based management | Yes |
| VLAN support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11v |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Channels quantity | 16 channels |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wireless LAN features | |
| Channels quantity | 16 channels |
| Network | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11v |
| Management features | |
| VLAN support | Yes |
| Syslog | Yes |
| Web-based management | Yes |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| VLAN support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11v |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Channels quantity | 16 channels |
| Number of VLAN IDs | 4096 |
| Maximal-Ratio Combining (MRC) | Yes |
| Fast roaming | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 575 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Security | |
| Security algorithms | EAP-TLS, EAP-TTLS |
| Ports & interfaces | |
| USB connector type | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 17.3 W |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 230 V |
| DC voltage range | 12 V |
| Design | |
| Placement | Ceiling, Wall |
| Country of origin | Germany |
| Product colour | White |
| LED indicators | Yes |
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Antenna features | Integrated antenna |
| Indication | |
| LED indicators | Yes |
| Software | |
| Number of VLAN IDs | 4096 |
| Maximal-Ratio Combining (MRC) | Yes |
| Fast roaming | Yes |
| Weight & dimensions | |
| Width | 205 mm |
| Depth | 205 mm |
| Height | 42 mm |
| Package weight | 1.72 kg |
| Packaging data | |
| Package weight | 1.72 kg |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Logistics data | |
| Country of origin | Germany |
| Quantity per pack | 1 pc(s) |
| Customs product code (TARIC) | 85176200 |
